Product Description
Product Description
Chongqing Ningcai Generate Power Co.,Ltd is a industry and trade co., LTD major in production & Sales generator set equipment. (SKYPE:liulin948)
75kw Weichai Diesel Generator Set
| TECHNICAL DATA OF DIESEL GENERATOR | |||
| MODE | GPDY-75GF | MAIN OUTPUT(KW) | 75 |
| VOLTAGE(V) | 230/380 | RATED CURRENT(A) | 135 |
| CONNECTION TYPE | 3-PHASE, 4-WIRE [Y" | POWER FACTOR | 0.8(lagging) |
| START MODE | 24V DC | FREQUENCY(Hz) | 50 |
| RATEED LOADING FUEL | <215 | GENERATOR DIMENSIONS | 2400×900×1500 |
| CONSUMP(G/KW.H) | (L×W×H)(OPEN-FRAME) | (mm) | |
| WEIGHT(kg) | 1300 | ||
| TECHNICAL DATA OF WEICHAI DIESEL ENGINE | |||
| MANUFACTURER | WEICHAI | MODE | R6105ZD |
| RATED ROTARY SPEED | 1500 | MAX CONTINUOUS OUTPUT | 90 |
| (RPM) | POWER (KW) | ||
| CYLINDER QTY | 6 | CYLINDER TYPE | IN LINE |
| BORE/STROKE (mm) | 105*125 | START WAY | ELECTRIC |
| COOLING METHOD | DUAL-CIRCULATE | FUEL | 0#LIGHT OIL |
| WATER COOLED | |||
| TECHNICAL DATA OF STANDFORD GENERATOR | |||
| MANUFACTURER | STANFORD | MODE | TZH-75 |
| POWER (KW) | 75 | EXCITING METHOD | BRUSH |
| SELF-EXCITATION | |||
| INSULATION GRADE | B | PROTECTION GRADE | IP22 |
| SCOPE OF VOLTAGE | ≥95%~105% | STEADY VOLTAGE | ≤±1% |
| ADJUSTMENT | GOVERNING RATE | ||
| EFFICIENCY | 80% | VOLTAGE ADJUSTMENT MODE | AVR(SX440) |
