GD-0193 Automatic Petroleum Oils Oxidation Stability Tester of Lubricating Oils (Rotary Oxygen Bomb Methods)

GD-0193 Automatic Oxidation Stability Tester







I Brief Introduction



The GD-0193 Automatic Oxidation Stability Tester  is designed and made as per SH/T0193 and ASTM D2272. It is suitable to determine oxidation stability of new or in service turbine oil, which has the same components (base oil and additive). It is also a rapid method for determining the oxygen stability of new mineral insulating oils containing 2, 6-Di-tert-butyl-p-cresol. It can check pressure, record test data, and calculate oxidation time for measured sample automatically. It can also end a test automatically. It can save test curves and test data automatically when show them on the display. The operators can print them out when needed. The test can be completed automatically without any human involvement after you start a test. This significantly lowers down the labor intensity of operators and highly improves the accuracy of test data. It is the best choice of companies for selecting an automatic instrument.



II Instrument parameters



Model	GD-0193 Automatic Lubrcating Oils Oxidation Stability Tester (Rotary Oxygen Bomb Method )
Power supply	AC220V±10%
Power of heater	2500 W
Full scale of pressure sensor	0~1.6MPa
Accuracy	±2‰
Temperature controlling range of oil bath	room temperature~200.0°C
Temperature controlling accuracy	±0.1 °C
Speed of rotary assembly	100±5 RPM
Angle between bomb and water surface	30 degree
Size	550mm×800mm×1000mm
Oil bath cubage	3L
Weight	about 45 kg





III  Packing &Delivery



Payment & Shipping Terms		Supply Capacity
Payment term :	T/T or L/C	Production capacity :	500pcs/month
MOQ:	1 pc	Packing :	Wooden case
Price	negotiable	Delivery way	By Air
Means of transport :	FOB , CIF , CFR	Delivery time :	10 days





IV Comapny Scan







Any More Information ,Pls Contact Us
