GDYJ-503 Insulating Oil Breakdown Voltage Laboratory Equipment
I Brief Introduction
GDYJ-503 Insulating Oil Breakdown Voltage Laboratory Equipment is developed according to the national standard GB-86 Insulating Oil Dielectric Strength Testing Method .The tester can test three cups of oil at the same time.LCD screen can display test procedure and test result. All the human interaction operations complete by the rotating mouse .It is very easy for customers to measure the breakdown voltage of all kinds of oil by HYYJ-503. You can print the test result by the micro printer internal the tester. Of course, you can upload the test data to PC from RS232 for data analyzing. The special circuit design makes the tester has a good performance at stability and anti-noise.
II Technique index
| Model | GDYJ-503 Insulating Oil Breakdown Voltage Laboratory Equipment | |
| Input voltage | AC 220V±10% | |
| Output voltage | AC 0~80KV | |
| Rate of voltage rise | 2KV/s±10% | |
| Measuring precision | 3 class | |
| Times | 1-6 | |
| Mixing time | 0~99 second | |
| Placing time | 0-9 minute 59second | |
| Voltage limit setting for proof test | 20KV----70KV | |
| Hold time for proof test | 0minute -----10 minutes | |
| Environment temperature | 5-40°C | |
| Relative humidity | ≤80%RH | |
| Size | 420×380×410mm3 | |
| Weight | 28kg | |
| Make a choice and combination at random between A,B and C cup | ||
III Characteistics
1 Breakdown test of user-defined
2 Proof test
3 Calibration interface for customers
4 Unloading data to PC and making word report automatically.
5 Result print
