GF Series dry air generator
I Brief Introduction
This equipment is suitable for supplying dry air which keeps the power equipments` inner parts from moisture in the maintenance of transformer, reactor and other big power facilities. Maintenance staff will not be short of oxygen working inside the equipment. It is more reliable, economic, convenient and safer than nitrogen.
II GF Series of different type
|
Item |
Parameter |
Model Unit |
GF-50 |
GF-100 |
GF-150 |
GF-200 |
|
|
Technical Parameter |
Flow |
M³/h |
50 |
100 |
150 |
200 |
|
|
Working Pressure |
Mpa |
0.6~0.8 |
|||||
|
Pressure Drop |
Mpa |
0.05 |
|||||
|
Noise |
dB(A) |
70 |
|||||
|
Working Power |
KW |
380V-50Hz 3 Phase 4 Wire |
|||||
|
Total Power |
KW |
12 |
19 |
22 |
26 |
||
|
Size |
Length |
cm |
215 |
215 |
230 |
230 |
|
|
Width |
cm |
155 |
155 |
165 |
165 |
||
|
Height |
cm |
230 |
230 |
230 |
230 |
||
|
Diameter |
DN |
32 |
40 |
50 |
50 |
||
|
Weight |
Kg |
900 |
980 |
1030 |
1050 |
||
|
After Treatment Index |
Discharge Pressure |
Mpa |
0.02~0.03 |
||||
|
Dew Point |
°C |
-50°C ~ -70°C |
|||||
|
Particle |
um |
0.01 |
|||||
|
Oil content in air outlet |
ppm |
0.01 |
|||||
