GDBC-901 Three Phase Transformer Turn Ratio Tester

Get Latest Price

Payment Type:: T/T, L/C, D/A

Incoterm:: FOB

Min. Order:: 1 Set/Sets

Min. Order:: 1 Set/Sets

Delivery Time:: 20 Days

Transportation:: Ocean, Land, Air

Quantity:

Your message must be between 20 to 2000 characters

Contact Now

Basic Info

Place of Origin:	Chongqing
Payment Type:	T/T,L/C,D/A
Incoterm:	FOB
Certificate:	CE SGS
Transportation:	Ocean,Land,Air

Product Description

Ⅰ. Introduction

GDBC-901 Automatic Transformer Turn Ratio Test meter is designed according IEC76-1 and IEC60044.

GDBC-901 Automatic Transformer Turn Ratio Test Meter could be applied to test the ratio of single or three phase transformer. Also the connection group of three phase transformer could be calculated with the ratio. All parameters are measured in one test for three phase transformer.

Ⅱ.Main Functions

1 The voltage ratio measurement for three or singe phase transformer

2 The group vector measurement for three phase transformer.

3 The polarity measurement for single phase transformer or CT/PT

4 Voltage ratio error calculation

5 Current transformer ratio measurement

6 Excitation current measurement in ratio testing

7 Reproduction the AC test voltage from power source to reduce the effects of bad power source

8 Save the test results in the memory internal the tester

9 Print the test results by micro printer

10 Reverse connection detect unit to prevent the high voltage injected to operator

11 Over current protection unit integrated in software and hardware

12 Upload the test results to PC by RS232 and make word report by software

Ⅲ. Technique Index

1 Ratio measurement range: 1-10000

2 Group measurement: 1-12

3 Phase measurement error: 1 degree

4 Ratio measurement error: 1-2000 ± 0.2%RDG 2000-10000 ± 0.5%RDG

5 Test voltage:0~80V, frequency 50Hz

6 Power supply: AC220V ± 10%, 50Hz/60Hz

7 Environment temperature: 0-50°C

8 Humidity: ≤85%RH

9 Size 400mm´350mm´200 mm Weight:7kg

1	The voltage ratio measurement for three or singe phase transformer
2	The group vector measurement for three phase transformer.
3	The polarity measurement for single phase transformer or CT/PT
4	Voltage ratio error calculation
5	Current transformer ratio measurement
6	Excitation current measurement in ratio testing
7	Reproduction the AC test voltage from power source to reduce the effects of bad power source
8	Save the test results in the memory internal the tester
9	Print the test results by micro printer
10	Reverse connection detect unit to prevent the high voltage injected to operator
11	Over current protection unit integrated in software and hardware
12	Upload the test results to PC by RS232 and make word report by software

1	Ratio measurement range: 1-10000
2	Group measurement: 1-12
3	Phase measurement error: 1 degree
4	Ratio measurement error: 1-2000 ± 0.2%RDG 2000-10000 ± 0.5%RDG
5	Test voltage:0~80V, frequency 50Hz
6	Power supply: AC220V ± 10%, 50Hz/60Hz
7	Environment temperature: 0-50°C
8	Humidity: ≤85%RH
9	Size 400mm´350mm´200 mm Weight:7kg
