GD-265H Kinematic Viscosity Test Equipment

Get Latest Price

Payment Type:: T/T, L/C, Western Union

Incoterm:: FOB

Min. Order:: 1 Set/Sets

Min. Order:: 1 Set/Sets

Delivery Time:: 15 Days

Transportation:: Ocean, Air, EXPRESS

Quantity:

Your message must be between 20 to 2000 characters

Contact Now

Basic Info

Place of Origin:	CHINA
Productivity:	20 SETS
Supply Ability:	10
Payment Type:	T/T,L/C,Western Union
Incoterm:	FOB
Transportation:	Ocean,Air,EXPRESS

Product Description

Summary

This instrument is designed and made as per the industry standard of People`s Republic of China SY/T5651 Technical Condition of Petroleum Products Kinematic Viscosity Tester, GB/T 265 Petroleum products-Determination of kinematic viscosity and calculation of dynamic viscosity and ASTM D445 Standard Test Method for Kinematic Viscosity of Transparent and Opaque Liquids.

It is suitable to determine kinematic viscosity of liquid petroleum products (Newtonian behavior) by measuring the time for a volume of liquid to flow under gravity through a calibrated glass capillary viscometer at a constant temperature.

I. Main technical features

1. Single chip and colored LCD technology. High intelligent and automatic type.

2. Intelligent signal sampling, data measuring, parameters operating, and result output. All the operations are finished automatically.English man-machine conversation interface. Easy to operate.

3. The instrument is equipped with timing function. It can choose valid flowing time period and calculate arithmetic average automatically. It can also preset the viscosity coefficient , calculate the viscosity after the test and print the test results automatically.

4. It can do one test alone or doing two tests at one time by setting the parameters.High efficiency.

5. It has the parameters saving function. The instrument will automatically save the parameters of capillary tube diameter, coefficient and so on after these parameters being setted. When doing test with the same capillary, no need to set these parameters again.

6. It adopts desktop and all-in-one machine design. Convenient to use.

II. Main technical specifications and parameters

1. Power supply:AC(220±10%)V,50Hz

2. Bath heating power:1700W

3. Temperature range:room temperature~100.0°C

4. Temperature control accuracy:±0.01°C

5. Bath volume:20L

6. Timing range: 0.0s~9999.9s

7. Timing accuracy: ±0.05% within 60min

8. Sample amount: 4 capillary viscometers at one time

9. Stirring motor: power is 6W, rotating rate is 1200RPM

10.Working condition: ambient temperature-10°C~35°C, RH: ≤85%

11.Temperature sensor: RTD, Pt100

12.Total power consumption: ≤1800W

13.Capillary viscometers: 7 pieces in total.The inner diameter for each: 0.6mm, 0.8mm, 1.0mm, 1.2mm, 1.5mm, 2.0mm, 2.5mm

14.Overall dimension: 530mm×400mm×670mm

We are a professional manufacturer of petroleum product analysis equipment, with many years of experience in research,which is in the leading position in China .

Our main products range is:

oil filter

Flash Point Tester,

Viscometer, Engler Viscometer,

Water Content Tester,

Kinematic Viscometer,

Distillation Tester,

Density Tester,

Rust and Corrosion Tester,

Sulphur Content Tester, etc.

We have developed sales channels in many countries and regions such as Japan, Korea, Hongkong, Taiwan, Regions of Southeast Asia, Middle East, Europe,

North and South America etc, and have gained strong advantage and high reputation in international market.

We have persisted on the business idea of "Integrity Basis and Quality First" for the stable and constant development.Client, quality and service are our supreme target!

All of the models promise good quality and one year overseas warranty .

Hope to establish reliable business relationship sincerely in coming days. Should you have any questions, please feel free to contact me.
