Mining Core Drilling Machice ZLJ-2900 Diesel Drilling Machine
- Payment Type:
- T/T, L/C, Western Union
- Incoterm:
- FOB
- Min. Order:
- 1 Set/Sets
- Min. Order:
- 1 Set/Sets
- Delivery Time:
- 7 Days
- Transportation:
- Ocean, Land, Air
Your message must be between 20 to 2000 characters
Contact Now| Place of Origin: | Chongqing |
|---|---|
| Productivity: | 300 sets per month |
| Supply Ability: | 300 sets per month |
| Payment Type: | T/T,L/C,Western Union |
| Incoterm: | FOB |
| Certificate: | ISO9001 |
| Transportation: | Ocean,Land,Air |
Specifications
ZLJ-2900 Tunnel Drilling Machine tunnel drilling machine for coal mining.
Coal Mining Exploration ZLJ-2900 Tunnel Drilling Machine
Applications & Features:
ZLJ-2900 tunnel drilling machine for coal mining is developed based on XY-2 drilling rig of spindle type core
drilling,it is suitable for tunnel engineering drilling with diamond bit,tungsten carbide bit in coal mining and underground exploration drilling for coal field.
It is light in weight,better quality,larger powered,wide performance and good interchangeavility
Technical Specifications
|
Project name |
unit |
numerical |
|
| Rated speed of rotation table shaft |
r/min |
63/108/172/238/ |
|
| Rated output torque of rotation table shaft |
N·m |
2900/1660/1030/ |
|
| Max.push force of spindle |
kN |
44 |
|
| Max.pull force of spindle |
kN |
60 |
|
| Max.feed speed of spindle |
m/min |
0~6 |
|
| Max.feed stroke < |
mm |
600 |
|
| Max.pull force of hoist with single |
kN |
30 |
|
| Drum dia. |
mm |
Φ200 |
|
| Wire rope dia. |
mm |
Φ14 |
|
| Drum capacity |
m |
45 |
|
| Drilling depth in theory |
m |
|
|
| Use drill pipe type | Φ42mm rod |
530 |
|
| Φ50mm rod |
|
385 |
|
| Φ60mm rod |
|
320 |
|
| AW rod |
|
530 |
|
| BW rod |
|
420 |
|
| NW rod |
|
320 |
|
| Drilling angle range |
º |
-90~+90 |
|
| Rated pressure of hydraulic system |
Mpa |
8 |
|
| Power of electric motor |
kW |
22 |
|
| Overal dimension |
mm |
2150×900×1690 |
|
| Weight(excluding power unit and rod) |
kg |
≈950 |
|
| Max.weight of detached part |
kg |
140 |
|
