XY-3 Mechanical Transmit And Hydraulic Feeding Spindle-type Core Drilling Machine
- Payment Type:
- T/T, L/C, D/P, Western Union
- Incoterm:
- FOB
- Min. Order:
- 1 Set/Sets
- Min. Order:
- 1 Set/Sets
- Delivery Time:
- 7 Days
- Transportation:
- Ocean, Land, Air
Your message must be between 20 to 2000 characters
Contact Now| Place of Origin: | Chongqing |
|---|---|
| Productivity: | 300 sets per month |
| Payment Type: | T/T,L/C,D/P,Western Union |
| Incoterm: | FOB |
| Transportation: | Ocean,Land,Air |
Specifications
APPLICATIONS
XY-3 Core Drill is a mechanical transmit and hydraulic feeding spindle-type core drilling machine. It is mainly used for core drilling with diamond bits for the exploration of solid mineral deposit.
1 Easy to operate and maintain.
2 Low running cost.
3 Compact and easy to disassemble and transport.
4 High power capacity.
5 Wide speed range for adjusting.
6 Hydraulic and manual chucks are equipped.
7 Diesel engine or motor equipped as required.
MAIN SPECIFICATIONS
|
DRILLING CAPACITY |
|
|
|
Core Drilling |
|
|
|
Φ54 Drilling Rod |
500m |
|
|
Φ60 Drilling Rod |
400m |
|
|
Φ73 Drilling Rod |
280m |
|
|
Wire-line Core Drilling |
|
|
|
Φ55.5 Drilling Rod |
600m |
|
|
Φ71 Drilling Rod |
450m |
|
|
Φ89 Drilling Rod |
300m |
|
|
DRILLING ANGLE |
0-360° |
|
|
SWIVEL HEAD |
|
|
|
Spindle I.D. |
76mm |
|
|
Spindle Speed (rpm) |
Forward |
33, 65, 109, 165, 215, |
|
Reverse |
36, 167 |
|
|
Spindle Stroke |
600mm |
|
|
Max. Torque of Spindle |
3600N.m |
|
|
Max. Pressuring Force of Spindle |
45kN, Max.55kN |
|
|
Max. Lifting Force of Spindle |
60kN, Max.75kN |
|
|
HOIST |
|
|
|
Hoist Capacity (Single Rope) |
32kN |
|
|
Lifting Speed (m/s) |
0.72, 1.20, 1.82, 2.38 |
|
|
Wire Rope |
Φ15mm |
|
|
Drum Capacity (Six Layers) |
55m |
|
|
HYDRAULIC PUMP |
|
|
|
Oil Pump |
CBK1016E/10E-B2FL |
|
|
Displacement (L/min) |
16+10L/min |
|
|
Working Pressure |
8MPa |
|
|
Max. Pressure |
10MPa |
|
|
SKID-TYPE FRAME |
|
|
|
Retraction Stroke |
460mm |
|
|
POWER UNIT(Optional) |
|
|
|
Electric MotorY180L-B35 |
22kW; 1480rpm |
|
|
Diesel Engine K4100ZHD |
31.1kW; 1500rpm |
|
|
Overall Dimension LxWxH (motor) |
2490X920X1880mm |
|
|
Overall Dimension LxWxH (Diesel) |
2615X920X1880mm |
|
|
Weight (without power unit) |
1300kg |
|
