1000m Armored Logging Cable Well Logging Cables

1000m Geological Well Logging Winch Cable 3/16" 4 Core Armoured Cable

Detailed Product Description

3/16" Armoured Cable
Geological Logging Use
Probe Use
Length: 0-5000m

3/16" Armoured Cable

Construction:
Copper Construction: 6× 0.20+1× 0.21 mm 6× 0.0078+1× 0.0082"
Insulation PP: 0.19 mm 0.00748"
Protection: 3.00 mm 0.118"
Armor: (Inner) 18× 0.47 mm(324N) 12× 0.0185"(72.8lbs)
(Outer) 18× 0.64 mm(601N) 18× 0.0251"(135lbs)

Physical:
Cable Diameter: 4.70mm± 0.10mm 0.18± 0.0039
Cable Weight in Air: 85 kg/km 57.4 lbs/kft
Temp Rating: 150 ° C 300 ° F

Mechanical:
Cable Breaking Strength: 13 kN 2900 lbs
Minimum Shave Diameter: 260 mm 10.5
Cable Stretch Coefficient: 4.78 m/km/5kN 4.25 ft/kft/klbs

Electrical:
Voltage Rating: 200 VDC 200 VDC
Insulation Resistance: 500 MΩ · Km 1500 MΩ · Kft
Resistance Typical: 84.3 Ω /km 25.6Ω /kft
Capacitance @ 1 kHz: 190 pf/m 58 pf/ft
