Cheap Underwater Water Well & Borehole Inspection Camera
- Payment Type:
- T/T
Quantity:
Your message must be between 20 to 2000 characters
Contact NowBasic Info
Basic Info
Place of Origin: | China |
---|---|
Payment Type: | T/T |
Product Description
Product Description
Product Description
I. Function:
1 To inspection the water leakaging of the well,
2 To imaging the blockage of the well
3 To help the repair of the well
4 Provide broadcast quality video of the underwater world
Back to the surface from up to within 1000m below,
5 This camea can be viewed in real time or recorded for later
Vieweing
II. Feature:
1 Super high resolution color picture
2 Low light operation
3 Led underwater light
4 Stainless steel housing
5 Military grade watertightness cable
6 Ability to attach up to deep place and stand large pressure
Of water.
1 To inspection the water leakaging of the well,
2 To imaging the blockage of the well
3 To help the repair of the well
4 Provide broadcast quality video of the underwater world
Back to the surface from up to within 1000m below,
5 This camea can be viewed in real time or recorded for later
Vieweing
II. Feature:
1 Super high resolution color picture
2 Low light operation
3 Led underwater light
4 Stainless steel housing
5 Military grade watertightness cable
6 Ability to attach up to deep place and stand large pressure
Of water.
No. | Product Configurations | Dimension | Specification |
1 | Probe | Dia.: 50/80mm Length: 470mm |
(1) Front lens are imported resins, (2) Not easy damaged, (3) Pressure is 1-16Mpa (can be under 3000m deep water) (4) Light: 9-11 LED Lights |
2 | Camera |
(1) Japan SONY inductor 1/3' ' CCD, (2) Image definition is HD 750 TVL (3 Watertight (4) Camera Angle: 180 degree |
|
3 | Professional logging cable |
Length: 100-3000m(optional) |
(1) With steel wire, (2) Tension is 150kg, (3) Destroy tension is 260kg |
4 | Main Control Host |
(1) 220V/380V/12V optional. (2) LCD dispaly is 8/15 inches. (3) Aircraft grade aluminum alloay material |
|
5 | Logging Winch | Hand or Electrical winch | |
6 | Lithography System | No disc-carving, but can |
