Gq-16 Water Well Drilling Rig, Geophysical Exploration Equipment and Well Drilling Rig

Get Latest Price

Payment Type:: L/C, T/T, Western Union

Quantity:

Your message must be between 20 to 2000 characters

Contact Now

Basic Info

Place of Origin:	China
Payment Type:	L/C, T/T, Western Union

Product Description

APPLICATIONS:

This drilling machine is newly designed and manufactured according to the requirement of foundation engineering, suitable for drilling medium mini-type grouting hole of building, skyscraper, dam and harbor and drilling water well.

FEATURES

1. Mast structure, top-drive head can move down or up along with, strength and rigidity
2. Large torque, compact structure, easy to move
3. Top-drive head is equipped with hydraulic chuck, drilling Efficiently.
4. Reasonable arrangement, easy to operate, smooth and quick.

Tecknical Specifications
hole dia (mm)		600
drilling capacity (m)		30
topdrive head speeds(r/min)	forward	40;118;218;300
	reverse	62
max torque (N.m)		4500
topdrive head max pull force (KN)		58.86
topdrive head max pulsh force (KN)		44.15
top-drive head stroke (mm)		700
hoist lift capacity with singlerope (KN)		30
retracting stroke (mm)		580
oil pump		CB32 oil gear pump
power unit	electric motor for rotary	Y180L-4 22KW
	electric motor for hoist	Y160M-4 11KW
innerdia if spindle (mm)		2200×1200×2050
drill body weight(kg)		2500
