Zgf DC High Voltage Generator /Electric Power Supply Generator

ZGF DC High Voltage Generator /electric power supply Generator
1.1 Introduction
ZGF DC high voltage generator is DC high voltage power supply equipment. It have functions of switch on protection under 0 voltage, over voltage and over current protection. They are high stability and reliability. ZGF is easy to operate, small in size and light in weight.
1.2 Function
DC high voltage test for the power supply department, for example: DC HV withstand and leakage current test in power cables, the conductance current and 1mA reference voltage of magnetic blow out arrester and zinc oxide arrester test.
Using as power supply of laser, also electrostatic painting and twine and so on.
Other place required DC high voltage.
1.3 Major parameters.
Model
Item
ZGF-60/2ZGF-120/2ZGF-120/5ZGF-200/2ZGF-300/2/3
ZGF-
200/400/2
Output Voltage60kV120kV120KV200kV300kV200 / 400kV
Output Current2mA2mA5mA2mA2 mA/3mA4 mA/ 2mA
Output Power120W240W600W400W600W/900W800W
Double voltage unit size145× 500(mm)
145× 800
(mm)
140× 800
(mm)
145× 1000(mm)145× 1300(m m)145× 1200
Operating unit size360× 260× 245(mm)(L× W× H)
Total weight10kg15kg17kg20kg25kg40kg
Ripple coefficientless than 0.5%
