Gdgs Precision Capacitance & Dissipation Factor Tester

GDGS Precision Capacitance & Dissipation Factor Tester

I. Application
1. GDGS automatic tan delta tester is applied to measure the dielectric loss and capacitor value of insulation materials in high voltage power equipment.
2. The non-power frequency voltage source is integrated in the tester to avoid power frequency interference.
3. The tester has a good performance in measurement precision.

II. Tangent delta tester technique index
1. Measurement error:
Capacitor value: 1%RDG+5pf
Tangent delta: 1%RDG+0.04%
2. Output voltage: AC 0.5kV~10KV
3. Testing voltage setting resolution: 0.5kv
4. Maximum output capacity: 200mA
5. Testing frequency: 45Hz/55Hz
6. Test mode: Fully automatic
7. Power supply: AC220V10 50Hz/60Hz
8. Environment temperature: 0~50~C
9. Humidity: ≤ 85%RH
10. Weight: 40KG

III. Two Models of GDGS Full-Automatic Tangent Delta Tester
