Gdyj-502 Automatic Transformer Oil 100kv Breakdown Voltage Tester

GDYJ-502 Automatic Transformer Oil 100KV Breakdown Voltage Tester


I. General Introduction
> GDYJ-502 Insulating Oil Breakdown Voltage Tester is developed according to the national standard GB-86 Insulating Oil Dielectric Strength Testing Method. LCD screen can display test procedure and test result. All the human interaction operations complete by the rotating mouse.
> GDYJ-502 Insulating Oil Breakdown Voltage Tester is very easy for customers to measure the breakdown voltage of all kinds of oil. You can print the test result by the micro printer internal the tester. Of course, you can upload the test data to PC from RS232 for data analyzing. The special circuit design makes the tester has a good performance at stability and anti-noise.

II. Functions
1 Breakdown test of user-defined
2 Proof test
3 IEC60156/IS6792/BS5874 test
4 ASTM D1816 standard test
5 ASTM D877 standard test
6 5 minutes standard test
7 Manual test
8 Calibration interface for customers
9 Uploading data to PC and making word report automatically.
10 Result print

III. Related Insulating Oil Dielectric Strength Tester
1 GDYJ-501 Transformer Oil Breakdown Voltage Tester
2 YJJ-II Insulating Oil Dielectric Strength Tester
3 GDYJ-503 Transformer Oil Breakdown Voltage Tester

IV. Parameters
