Gdj-II 80kv Transformer Oil Breakdown Voltage Tester

Max. 80KV Voltage rise
Pre-setting voltage rise speed and stirring times
Auto-calculate for average value and auto-print
Standard 400 ml Oil Cup
Power cable and Ground wire
One pair of electrode
Print paper

II. Functions:
1. Breakdown test of user-defined (Max. 80KV)
2. Proof test
3. Calibration interface for customers
4. Result print
III. Technique index:
Output voltage: AC 0~80KV2
Rate of voltage rise: 2KV/s± 10%
Measuring precision: 3%RDG+0.3%FS
Test times setting: 1-9
Mixing time setting: 0~99 second
Waiting time setting: 0-9 minute 59second
Maximum storage capacity: 100 groups of test data
Test standards: IEC60156
Display: LED
Rated power supply: AC 220V± 10% 50/60Hz
Environment temperatures: 0-50° C
Relative humidity ≤ 80%RH
Size: 420mm´ 325mm´ 300mm
Weight: 28kg
