Gd-261-1 Semi-Automatic Pensky-Martens Closed Cup Flash Point Tester

GD-261-1 Semi-Automatic Pensky-martens Closed Cup Flash Point Tester


Summary:
GD-261-1 Semi-Automatic PMCC Flash Point Tester is designed and manufactured as per standards GB/T 261-2008 Determination of Flash Point - Pensky-Martens closed cup method and ASTM D93 Standard Test Methods for Flash Point by Pensky-Martens Closed Cup Tester.
GD-261-1 Semi-Automatic PMCC Flash Point Tester is used to make determination of the closed cup flash point of the petroleum products in the temperature range from 40° C to 360° C.

I. Main technical features
1. Single chip microcomputer control technique. LCD screen displays. English man-machine interaction interface. The heating power is continuously step-less adjustable. The rate of heating up is exact. Easy setting for parameters.
2. The LCD screen has prompting menu, prompting input operation interface. It shows the setted parameters, real-time temperatures and other test parameters. Press the "record"button when the flash point appears. The screen will show and reserve the flash point.
3. The structure is newly design and small. Stainless steel table-board looks clean and beautiful. It can be used as long as equipped with gas or other civilian fuels. It is easy to use and test results exact.

II. Main technical specifications and parameters
1. Power supply: AC 220V± 10%, 50 Hz;
2. Heating device:
(1) The material of furnace is silicon carbide, the power of heating wire is 600W
(2) The heating power can be continuously adjusted in the range of 0~600W;
3. Sample temperature rising speed:
Procedure A: (5~8)° C/min;
Procedure B: (1~1.5)° C/min;
Automatic control.
4. Electric stirring device:
(1) Stirring motor: BYGH101 stepper motor
(2) Driving mode: Flexible shaft coupled
(3) Dimension of stirring blades: 8× 40mm
5. Stirring speed: Accord with the requirement of GB/T261-2008
(1) 90~120 RPM, for procedure A;
(2) 250± 10 RPM, for procedure B;
6. Flame ignition device:
(1) Gas source: Coal gas (or other civil combustible gas, similarly hereinafter)
(2) Spout diameter: 0.7~0.8 mm
7. Temperature sensor: PT100
8. Ambient temperature: ≤ 35° C;
9. Relative humidity: ≤ 85%;
10. Total power consumption: Not more than 650 W;
11. Overall dimension: 340*330*380mm (Length*Width*Height)
