Gd-1884 ASTM D1298 Petroleum Products Density Tester

GD-1884 ASTM D1298 Petroleum Products Density Tester

I. Application
GD-1884 ASTM D1298 Petroleum Products Density Tester is designed and made as per the National Standard GB/T 18842000 "Test Methods for Density of Petroleum and Liquid Petroleum Products (Densimeter Methods)".
GD-1884 ASTM D1298 Petroleum Products Density Tester is suitable to determine density of liquid petroleum products using a densimeter.

II. Working Condition
1. Ambient temperature: -10° C ~ +40° C; The temperature should not change for more than ± 2° C;
2. Relative humidity: ≤ 85%;
3. The instrument should be placed on a flat workbench during operation and please try your best to reduce air convection during a test.
4. If the instrument is not used for a long time, please store it at a dry place.

III. Technical Parameters
1. Power supply: AC 220V± 10%, 50 Hz;
2. Cubage of bath: 300× 380 mm;
3. Heating power: 700 W; 1000 W;
4. Temperature controller:
(1) Temperature controlling range: 0Centigrade~100Centigrade;
(2) Temperature controlling accuracy: ± 0.2Centigrade;
(3) Temperature sensor: Industrial platinum resistance, Pt100;
5. Thermometer: Total immersion mercury thermometer with scale division of 0.2 Centigrade

IV. Full Set
