Gd-265D-1 ASTM D445 Petroleum Products Kinematic Viscosity Bath

GD-265D-1 ASTM D445 Petroleum Products Kinematic Viscosity Bath


I. Introduction
» GD-265D-1 ASTM D445 Kinematic Viscosity Bath is designed and made as per the industry standard of People's Republic of China SY/T5651 Technical Condition of Petroleum Products Kinematic Viscosity Tester, GB/T 265 Petroleum products-Determination of kinematic viscosity and calculation of dynamic viscosity and ASTM D445 Standard Test Method for Kinematic Viscosity of Transparent and Opaque Liquids.
» GD-265D-1 ASTM D445 Kinematic Viscosity Bath is suitable to determine kinematic viscosity of liquid petroleum products (Newtonian liquids) by measuring the time for a volume of liquid to flow under gravity through a calibrated glass capillary viscometer at a constant temperature.

II. Main Technical Features
1. The instrument is a kind of specially-made testing machine which the temperature control accuracy can reach ± 0.01° C and having digital display.
2. It adopts hard glass bath and heat preservation cover(double shell). Good heat prevention and easy to observe the sample.
3. It adopts desktop and all-in-one machine design, convenient to use.
4. It adopts electric stirrer to ensure the uniform of bath temperature.

III. Main Technical Specifications
1. Power supply: AC 220 ± 10 %, 50 Hz.
2. Heating power: 1000W(auxiliary heating), 600W(temperature control heating)
3. Power for stirrer: 6W, rotating speed: 1200RPM
4. Temperature range: Room temperature~100 ° C.
5. Temperature control accuracy: ± 0.01° C.
6. Timer: 0.0s~999.9s
7. Constant temperature bath: 20L, double shall structure.
8. Ambient temperature: -10° C~+35° C
9. Relative humidity: <85%.
10. Maximum power consumption: 1800W.
11. Capillary viscometer tubes(Pinkevitch viscometer): 7 pieces in total. The inner diameters for each: 0.6, 0.8, 1.0, 1.2, 1.5, 2.0 and 2.5mm
12. Dimension: 530mm× 400mm× 670mm Net weight: About 42Kg

Note: This instrument is equipped with 7 pieces of Pinkevitch viscometers. We can customize instrument equipping with Ubbelohde viscometers according to customer's requirements.
