Series IIJ-II-100KV Portable Transformer Oil Analyzer Kits with CE,ISO,IEC156 Standards

Application:

IIJ-II series fully automatic oil tester is apply to test the insulating oil's dielectric strength, which is designed as per the requirement of IEC165 Testing Method of Insulation Oil Medium Strength, which via proper programming, has got functions of auto boosting, step down, stirring, display and print out. After breakdown of oil medium, HV break off will operate within 10 seconds to enable an auto isolation of control system partly; this effectively safeguards the personnel security and equipment safety.

Features: The automatic oil tester adopt industrial SCM to control which is applied to integrate circuit, new model I/0 connection , particular testing and anti-jamming technology which is largely improved the machine's capacity .

Main features:

1. Simply operate: automatically (can be finished just press on key)

2. Menu controlled. Input data can clear

3. Can store 99 groups' oil testing data which is convenient to reading and print. The testing data can keep 100 years under the condition of power off.

4. System time can go on running under power off; (The system time just for reference can not be the standard of timing)

5. Can upgrade software through RS232

6.High capacity of anti-jamming and high precision of testing.

7. Small volume, light which operated in the open air very conveniently.

Technology and parameter data

1. Power supply: AC220V ±10%, 50 HZ

2. Output voltage: 60 kV, 80 kV, 100 kV (100 kV should be specially designed)

3. Capacity: 1.2 kVA (for 60kV), 1.6 kVA (for 80 kV), 2.0 kVA (for 100 kV)

4. Pressure increase speed: about 2 kV/S

5. Voltage inspection accuracy:   3%

6. Dielectric strength sensitivity: <2KV

7. Wave from distortion:   < 3%

8. Breakdown response time:   <10ms

9. Polar distance:   2. 5mm

10. Working environment: temperature: 0 to 40 º C, humidity: <85% (Relative Humidity)

11. Storage environment: temperature: -20 to 60 º C, humidity: <75% (Relative Humidity)

12. Working Altitude: < 1500 meters. (If over 1500m, it can be customized)

13. Dimensions and weight: 38 x 37 x 38 cm. Net: 40 kg (Approximately)


Our oil tester/ analyzer:  1. Transformer oil Breakdown voltage Tester (BDV test kit) series IIJ-II

2. Acidity tester model ACD-3000I

3. Karl Fischer Water content Tester Model TP-6A / model TP-2100

4. Fully automatic Interfacial Tension Analyzer model IT-800

5. Gas-Chromatography transformer oil gas analyzer model DGA2013-1

6. Multi-functional Vibration tester model TYD-2000

7. Consolidation Point Determinator model PT-2000

8. Kinematic Viscosity tester model VST-8 /model VST-2000

9. Flash point tester (open cup) model TPO-3000

10. Flash point tester (close cup) model TPC-3000

11. TAN-DELTA TESTER, 10kV Capacitance and Dissipation Factor Test Set model CDEF

12. Automatic Freezing Point & Pour Point Tester model TP-501Z

13. Determination of foaming characteristic of lubricating oil model SD-12579

14. Earth resistance tester model HYDW-II

15. Coil Resistance Tester (TPZC-40)

16. CT/PT tester model TPVA-404

17. Transformer turn ratio tester model HYG-II

18. Relaying Protection Tester model TPJB-III

19. Digital Grounding Resistance Tester model TP2571-II

20. DC High Voltage Generator model ZGF

21. Underground water/gold detector model TP-UWD
