Waste Industrial Plate Pressure Oil Cleaning Equipment, Manually Press Operation, Fast Remove Water and Particles

Get Latest Price

Payment Type:: L/C, T/T

Quantity:

Your message must be between 20 to 2000 characters

Contact Now

Basic Info

Place of Origin:	Chongqing, China
Payment Type:	L/C, T/T

Product Description

Waste industrial plate pressure oil cleaning equipment, manually press operation, fast remove water and particles

Specifications
Plate pressure oil cleaning equipment
1. Remove water, impurities
2. Small, light
3. Manually operating

Application:
PL series plate pressure oil purifier is specially designed for power station, electricity factory, mineral enterprise, lube depot, tractor station, petroleum, chemical engineering, metallurgy, national defense unit, ect, filtering water and impurities of transformer oil, turbine oil, engine oil, diesel oil, kerosene, aviation hydraulic oil, as well as filtering edible oil while using stainless steel. The machine is made up of filter bed, oil pump and rough filter. There are filtering media, such as filtering paper or filtering fuse, installed between the plastic filter board and filter plate that will be fixed to form a single filtering room under the pressure of the packing device. The filtering paper or filtering fuse packed between the filter board and filter plate will play a role of filtering. It's characterized by simple structure, easy operation, low operation cost, ect.
Our oil filtration machine:
Series ZY Single-Stage Vacuum Transformer Oil Purifier
Series ZYD Double High Vacuum Transformer Oil Purifier
Series ZYB Multiply-Function insulating oil treatment machine
Series TY Turbine Oil Purification Apparatus
Series TYA Lubricating oil/ hydraulic oil purification unit
Series TYB Portable light Fuel oil purification machine
Series TYD Vacuum dehydrator
Series TYF Phosphate ester fire-resistance oil purifier
Series PL Plate pressure oil purifier
Series TYD Vacuum dehydrator
Series EFD Explosion protection filtration machine
Series BAM Press filtration system
Series ZKCC Vacuum pumping device
Series COP Cooking oil purification machine
Series CYS Centrifugal oil purification machine
Series JL Portable oil filtering and oiling machine
EOR series waste engine oil recycling system
Our oil tester/ analyzer:
Series IIJ-II Insulating oil breakdown strength tester(oil BDV tester)
Series HTJS-H Insulating oil dielectric tester (dielectric loss tester for insulating oil)
Series HTJS-V Tan-Delta Tester (anti-jamming dielectric loss tester for HV electrical equipment)
Series TP-3A Water content tester/ moisture sensor
Series TPV-8 Viscosity analyzer
Series TPC-2100 Flash point analyzer (close cup)
Series TPO-2100 Flash point analyzer (open cup)
Series CL-3 Interfacial tension analyzer

Model		Unit	PL-30	PL-50		PL-100		PL-125		PL-150		PL-200		PL-300
Flow Rate		L/min	>30	>50		>100		>125		>150		>200		>300
Working Pressure		MPa	0-0.5
Filter Size		≥ m 2	0.3	0.39		1.3		1.54		1.89		2.01		3.1
Add Pressure			Manually
Filter Room Number			11	13		10		12		14		18		23
Filter Plate Number			12	14		11		13		15		19		24
Oil Pump	Flow rate	L/min	>30	>50		>100		>125		>150		>200		>300
	Pressure	Mpa	0.6
Power			380V/3P/50Hz (or as needed)
Motor	Power	kW	1.1			4				3				5.5
	Speed	r/min	1400
Filtering Precision			≥1μ
Filter Paper Size			185*190			285*290
Diameter	Inlet	mm	32		32		44		44		50		50		65
	Outlet	mm	25		25		32		32		44		44		50
Dimension	Length	mm	700		750		900		900		1100		1100		1300
	Width	mm	300		300		440				440				440
	Height	mm	720		840						1000
Weight		kg	76	86		130		180		210		230		280
