Series Zy Vacuum Insulation Oil Purifying Machine Removing All Kinds of Impurities From Used Oil

Get Latest Price

Payment Type:: L/C, T/T

Quantity:

Your message must be between 20 to 2000 characters

Contact Now

Basic Info

Place of Origin:	Chongqing, China
Payment Type:	L/C, T/T

Product Description

Series ZY Vacuum Insulation Oil Purifying Machine Removing All Kinds of Impurities From Used oil

Specifications

Vacuum insulation oil purifying machine

1.GB/T9001:2000-ISO9001:2000
2.with lastest technology
3.best after sales service

Application:

ZY oil purifier is high efficiency vacuum insulating oil purifier(oil purification, oil filtration, oil recycling), mainly for the power station, industrial and mining enterprises purifying the unqualified transformer oil, mutual inductor oil, switch oil and so on. Series ZY can remove water, trace water, gas, particles from oil quickly and effectively, improving oil dielectric strength. Also, this oil purifier can be used to power equipments to vacuum drying, and vacuum oiling.

Features:
1.Duplex-Stereo film evaporation technology, combined with unique and advanced dewatering, degassing components, can rapidly and effectively separate water, gas from oil.
2. Multi-stage precision filtration system, mesh filtration combined with molecular adsorption technologies
3. Efficient electric heating system, heating uniformity, less power consumption, safe, and reliable.
4. Double-infrared liquid level sensor, pressure protective system to ensure the machine operation easy and safely.
5. Adopts interlocked protective system, which connect oil pump, heater and liquid level sensor, avoiding blank heating, blank pumping, oil leak and electricity leak. If there is any fault, machine will be power off automatically.
6. Working with BZ insulating oil regeneration device to decolor (remove acid, oxide, free carbon) and lower dielectric loss, making the treated oil more limpidity

Why do we choose oil purifier?

After a period of operation, owing to its exposal to oxygen and mixed with water, copper and iron and other foreign materials and high working temperature acceleration , transformer oil will oxidize and lose its original property and cannot be used effectively again. So TOP oil purifiers can efficiently remove water, dirt, gases and other foreign impurities from oil, such as de-electrical oil, turbine oil, lubricating oil, engine oil, hydraulic oil, compression oil, mechanical oil, quenching oil, heat conducting oil, gear oil etc; so as to maintain its lubricating and insulating property, then to reduce components wear, and cut down oil expenses.

What Oil can we process?

We can process turbine oil, transformer oil, insulation oil, switch oil, capacitor oil, gear oil, vacuum pump oil, bunker oil, engine oil, hydraulic oil, black oil, diesel, freezer oil, compressor oil, vacuum pump oil, heat treatment oil, fire-resistant oil, machinery oil and other lubricant oils.

Series Zy Vacuum Insulation Oil Purifying Machine Removing All Kinds of Impurities From Used Oil

(oil purifier, oil purification, oil filtration, oil recycling, oil treatment, oil regeneration, oil restoration, oil filtering, waste oil disposal, oil reclaiming, waste oil management, energy saving, oil reconditioned, oil reconstituted, oil restituting, oil recovering ,oil filtration, oil filter, petroleum machine, oil tester, oil analyzer, testing equipment)

Parameters		Unit	ZY-6	ZY-10	ZY-20	ZY-30	ZY-50	ZY-100	ZY-150	ZY-200	ZY-300
Flow rate		L/h	360	600	1200	1800	3000	6000	9000	12000	18000
Vacuum degree		MPa	-0.06~-0.095
Working pressure		MPa	≤0.3	≤0.4	≤0.4	≤0.4	≤0.5	≤0.5	≤0.5	≤0.5	≤0.5
Temperature range		°C	20 ~ 80
Continuous working		H	150
Power supply			Three phase,50HZ ,380V(or as per customer requirement)
Working noise		dB(A)	60	61	63	70	70	75	70	70	70
Heating power		kW	9	11	13	15	30	48	58	70	85
Total power		kW	9.7	12.5	14.5	16.5	33.5	53	65	76	94
Oil inlet/outlet		mm	φ20	25	φ25	φ25	φ32	φ42	φ50	φ50	φ60
Weight		Kg	150	230	250	270	300	500	700	900	1100
Size	L	mm	970	1050	1100	1150	1200	1600	1600	1800	1900
	W	mm	630	750	850	900	950	1000	1100	1200	1200
	H	mm	900	1300	1400	1450	1500	1800	1800	1900	1900

Guarantee Value

Item	Guarantee indexes
Moisture content	≤5PPM
Impurity size	≤1 micron
Gas content	≤0.1%
Breakdown voltage	≥70
