Trailer Type Mobile Insulating Oil Purification Equipment (ZYM-150)

Mobile type Insulating Oil Purifier Series ZYM
1.Portable
2.Environment proction
3.High quality

Application:

According to fieldwork requirement, this machine equips the car wheels, which can be easy to move to any work point by traction. It is special suitable for purifying the transformer oil which locate in different fields. This machine can recover the seriously transformer oil. The treated transformer oil can reuse again in transformer.

Features:

1. Mobile (trailer) type, completely closed structure, waterproof, dustproof, move easy.

2. Installation of car tyres, Bridge shock absorber, braking system and steel welding of entire trailer guarantee 60km/h speed.

3. Dealing with unqualified insulating oils, rapidly remove water, gas, particles from oil

4. Multi-stage precision filtration system, mesh filtration combined with molecular adsorption technologies

5. Efficient electric heating system, heating uniformity, less power consumption, safe, and reliable.

6. Double-infrared liquid level sensor, pressure protective system to ensure machine operation easy and safely.

7. Adopt interlocked protective system, which connect oil pump, heater and liquid level sensor, avoiding blank heating, blank pumping, oil leak and electricity leak. If there is any fault, machine will be power off automatically.

Advantages:

Mobile (trailer) type, completely closed structure, waterproof, dustproof, it can move long distance working in field.

Optional Features :

• An exhaust condenser to measure the extracted water
• Condenser is equipped to settle the most volatile oil fractions which might distil back to the column
• Digital temperature measurement
• Digital precision vacuum gauge
• Digital flow meter
• Digital in line moisture content meter
• Ionic reaction columns to remove the acidity from the oil
• Audio / Visual fault annunciation System
• PLC control system
• Mobile Trailers can be provided
• Fully-enclosed and Semi-enclosed for weather-proof are available

After -sales Service

1.Two years guarantee for product quality. (except man-made damage)

2.Free training , installation and testing are available

3.Lifelong maintenance Service

4.Spare parts supply

Index after purification (test at oil-outlet of the machine) :

water content≤ 3ppm

gas content≤0.1%( by volume)

acetylene content:0

breakdown voltage≥75KV (Spherical polar)

particle qty in 100ml oil≤500 (5-50 micron), (0 for ≥100 micron particle).

dielectric loss tgδ≤0.3% (90°C)

acid value ≤0.1mgKOH/g
