New 3kw diesel generator/small portable diesel generator

New 3kw diesel generator/small portable diesel generator

Get Latest Price

Payment Type:: L/C

Quantity:

Your message must be between 20 to 2000 characters

Contact Now

Basic Info

Payment Type:	L/C

Product Description

Suitable for:

Business: shops, restaurants, workshops, hotels, offices, farms
Social: education, training and culture school or institution, medical center, clinique, organization and government department, religion center, entertainment and sport center
Residential: Villa area, residence community, activity outdoors
Max. output power: 5.0kVA
Low noise design, 82 dB(A) at 4mts
Lightweight and compact
A full tank of fuel can last for 6.5 constant hours
E indicate electric starter (Optional)
Optional: battery, wheels, handles and supporting leg

Specifications:

Model: WD-3000CE
Rated frequency (Hz): 50/60
Rated output (kVA): 3.5/4.0
Max. output (kVA): 3.0/3.5
Rated voltage: 220/230/240/220/110/240/120V (For option)
Rated current (A): 39.2/19.6 41.7/20.8
Rated speed (r/min ): 3000/3600
Phase No.: 1/3 phase
Power factor (cosφ): 1
Insulation grade: B
Pole number: 2
Excitation mode: self-excitation and constant voltage(AVR)
Panel type: general
Output voltage: 220/230/240/220/110/240/120V (For option)
Receptacle (mm): Two receptacles
Connection pole: Without
DC12V output: Connection pole output
Overall dimension: 655×480×530mm
Dry weight (Kg):
- C: 65
- E: 70
Working assorting:(Kg)
- C: 78
- E: 83
Noise level: 7M/db (A) 77
Structure type: Open frame
Engine model: 178FA
Engine type: single-cylinder, vertical, 4-stroke, direct injection
Cylinder No, bore stroke: 1-78×64mm
Displacement: 296
Rated power kW(Hp)/(r/min): 3.0/3000, 3.5/3600
Compression ratio: 20:01
Rated rotation speed 3000/3600

lgnition system:

Cooling system: Air cooled
Lubrication system: pressure splashed
Starting system:
- C: Recoil
- E: Electric starter
Fuel type: 0#(summer)-10#(winter)-20#(chillness)disel
Lube oil: Brand CD grade or SAE10W-30,15W-40
Capacity of cooling Water(L) Without
Lube capacity: 1.1l
Starting motor capacity (V-kW) 12V 0.8kW
Charging generator capacity (V-A) 12V/3A
Battery capacity (V-Ah): 12V/36Ah
Fuel consumption (g/kW·h) 275.1 281.5
Fuel tank capacity (L) 13.5
Continuous running time: 11hr

Why choose us:

Manufacturing expenrience
Professional engineers and test equipments to ensure the quality of each machine
OEM service is available
High quality control system
Convenient use
DHV OHV, operation reliable
Low noise and small vibration
After-sales

Business: shops, restaurants, workshops, hotels, offices, farms

Social: education, training and culture school or institution, medical center, clinique, organization and government department, religion center, entertainment and sport center

Residential: Villa area, residence community, activity outdoors

Max. output power: 5.0kVA

Low noise design, 82 dB(A) at 4mts

Lightweight and compact

A full tank of fuel can last for 6.5 constant hours

E indicate electric starter (Optional)

Optional: battery, wheels, handles and supporting leg

Model: WD-3000CE

Rated frequency (Hz): 50/60

Rated output (kVA): 3.5/4.0

Max. output (kVA): 3.0/3.5

Rated voltage: 220/230/240/220/110/240/120V (For option)

Rated current (A): 39.2/19.6 41.7/20.8

Rated speed (r/min ): 3000/3600

Phase No.: 1/3 phase

Power factor (cosφ): 1

Insulation grade: B

Pole number: 2

Excitation mode: self-excitation and constant voltage(AVR)

Panel type: general

Output voltage: 220/230/240/220/110/240/120V (For option)

Receptacle (mm): Two receptacles

Connection pole: Without

DC12V output: Connection pole output

Overall dimension: 655×480×530mm

Dry weight (Kg):

C: 65
E: 70

Working assorting:(Kg)

C: 78
E: 83

Noise level: 7M/db (A) 77

Structure type: Open frame

Engine model: 178FA

Engine type: single-cylinder, vertical, 4-stroke, direct injection

Cylinder No, bore stroke: 1-78×64mm

Displacement: 296

Rated power kW(Hp)/(r/min): 3.0/3000, 3.5/3600

Compression ratio: 20:01

Rated rotation speed 3000/3600

C: 65

E: 70

C: 78

E: 83

Cooling system: Air cooled

Lubrication system: pressure splashed

Starting system:

C: Recoil
E: Electric starter

Fuel type: 0#(summer)-10#(winter)-20#(chillness)disel

Lube oil: Brand CD grade or SAE10W-30,15W-40

Capacity of cooling Water(L) Without

Lube capacity: 1.1l

Starting motor capacity (V-kW) 12V 0.8kW

Charging generator capacity (V-A) 12V/3A

Battery capacity (V-Ah): 12V/36Ah

Fuel consumption (g/kW·h) 275.1 281.5

Fuel tank capacity (L) 13.5

Continuous running time: 11hr

C: Recoil

E: Electric starter

Manufacturing expenrience

Professional engineers and test equipments to ensure the quality of each machine

OEM service is available

High quality control system

Convenient use

DHV OHV, operation reliable

Low noise and small vibration

After-sales
