Basic Info

Place of Origin:	China

Product Description

*Product Name: Ship Roller Fairlead
*Size: 19-68mm
*Surface: Gray Zinc Rich Primer, as required
*Standard: CB*3062-79, JIS F-2026
*Certificate: CCS ABS BV NK KR GL LR RINA RMRS

*Packing: Steel Pallet, as required

Steel Wire
Dia.

	Nylon Rope Dia.	E	F	D	d	L	L1	L2	L3	B	B1	B2	H	H1	Weight kg
19.5	36	200	257	100	40-0.5	644	416	300	544	238	194	108	508	330	138
22.5	40	200	275	120	50-0.5	728	456	320	608	280	232	128	552	360	212
26.0	45	200	311	130	55-0.5	776	480	330	646	304	250	138	606	405	273
32.0	70	220	328	150	65-0.5	880	540	370	730	346	288	158	670	435	401
34.5	80	240	358	160	70-0.5	940	580	400	780	370	308	168	710	470	469
37.5	85	240	383	180	80-0.5	1030	620	420	850	417	345	190	770	510	678
43.0	95	260	411	200	90-0.5	1136	686	460	836	459	385	210	820	550	866
52.0	100	260	450	230	100-0.5	1256	746	490	1026	521	445	240	910	605	1197
60.5	-	300	493	260	120-0.5	1430	850	560	1170	590	500	270	1000	670	1741
68.0	-	320	563	320	150-0.5	1690	990	640	1370	714	620	330	1130	770	2811
