HI-Target V90plus GPS RTK ROVER ANTENNA FOR CORS MEASURMENTS

                                                  V90 PLUS GNSS RTK SYSTEM

With a hi-tech, fully integrated design, the conveniently sized V90Plus is one of the most flexible choices for any measuring task. Built-in Linux3.2.0 operating system, pre-loaded multiple smart applications such as tilt surveying, electronic bubble calib.

Satellite Signals Tracked Simultaneously
220 Channels
GPS---.. Simultaneous L1C/A, L2C, L2E, L5
GLONASS-----..Simultaneous L1C/A, L1P, L2C/A (GLONASS M only), L2P
SBAS--------. Simultaneous L1 C/A, L5
Galileo------... Simultaneous L1 BOC, E5A, E5B, E5AltBOC
BDS------..--.-----------. B1, B2
QZSS--------.. L1 C/A, L1 SAIF, L2C, L5

POSITIONING PERFORMANCE

Static and Fast Static GNSS Surveying
Horizontal--------2.5mm+0.5ppm RMS
Vertical----------. 5mm+0.5ppm RMS

Post Processing Kinematic (PPK / Stop & Go) GNSS Surveying
Horizontal---------.. 1cm+1ppm RMS
Vertical---------- 2.5cm+1ppm RMS
Initialization time---.Typically 10 minutes for base while 5 minutes for rover
Initialization reliability--Typically > 99.9%

Real Time Kinematic (RTK) Surveying
Single Baseline
Horizontal---------.. 8mm+1ppm RMS
Vertical----------. 15mm+1ppm RMS


Network RTK
Horizontal---------.. 8mm+0.5ppm RMS
Vertical----------.. 15mm+0.5ppm RMS
Initialization time--..-Typically < 8seconds
Initialization reliability--.Typically > 99.9%

Code Differential GNSS Positioning
Horizontal---------. 25cm+1ppm RMS
Vertical----------- 50cm+1ppm RMS
SBAS --- 0.50m Horizontal, 0.85m Vertical

HARDWARE
Physical
Dimensions (W x H)--.153mm x 83mm (6.02inch x 3.27inch)
Weight---950g (2.09lb) without internal battery
Operating temperature---. -40℃to +65℃ (-40℉ to +149℉)
Storage temperature----. -40℃ to +75℃(-40℉ to +167℉)
Humidity---------. 100%, considering
Water/dustproof------.. IP67 dustproof, protected from temporary immersion to depth of 1m (3.28ft).
Shock and vibration-----Designed to survive a 3m(9.84ft) natural fall onto concrete.

Electrical
Power 6V to 28V DC external power input
Power consumption ≤3.5W
Automatic switching between internal power and external power
Rechargeable, removable 7.4V, 5000mAh Lithium-ion battery in internal battery compartment

Internal Battery Life
Static 12hours
RTK rover (UHF/GPRS/3G) 8-10 hours
RTK base 8 hours

I/O Interface
1 xBluetooth, NFC
1 x standard USB2.0 port
1 x TNC antenna connector
1 x RS232 serial port
1 x DC power input (5-pin)

Tilt Survey System
Electronic Bubble

COMMUNICATION
Network Communication
Fully integrated, fully sealed internal WCDMA, compatible with GPRS, GSM
Wifi frequency is 2.4G, supports 802.11b/g/n protocol
Network RTK (via CORS) range20-50km

HI-TARGET Internal UHF Radio(Standard)
Frequency- 450~470MHz with 116 channels
Transmitting power-0.5W, 1W, 2W adjustable
Transmitting speed---.9.6Kbps, 19.2Kbps
Working range----.3~5km typical, 8~10kmoptimal

Pacific Crest XDL Micro Internal UHF Radio
Frequency-----------.403~473MHz
Transmitting power------ 0.5W, 2W adjustable
Transmitting speed-----.. Up to 19.2Kbps
Support most of radio communication protocol
Working range--------- 3~5km typical, 8~10km optimal

HI-TARGET External UHF Radio (Standard)
Frequency---- 460MHz with 116 channels
Transmitting power--. 5W, 10W, 20W, 30W adjustable
Transmitting speed----- Up to 19.2Kbps
Working range-------. 8~10km typical, 15~20km optimal

Pacific Crest ADL Vantage Pro External UHF Radio
Frequency-. 390~430MHz or 430~470MHz
Transmitting power-.. 4W to 35W adjustable
Transmitting speed-----.. Up to 19.2Kbps
Support most of radio communication protocol
Working range-. 8~10km typical, 15~20km optimal

SYSTEM CONFIGURATION
System
Data storage-------16GB Internal storage (Support up to 32GB external SD card)
Record GNS and RINEX format simultaneously

Data Formats
1Hz positioning output, up to 20Hz
CMR: CMR, CMR+, sCMRx input and output
RTCM: RTCM 2.1, 2.3, 3.0, 3.1, 3.2 input and output
Navigation outputs ASCII: NMEA-0183 GSV, AVR, RMC, HDT, VGK, VHD, ROT, GGK, GGA, GSA, ZDA, VTG, GST, PJT, PJK, BPQ, GLL, GRS, GBS
Navigation outputs binary: GSOF
