GPS Accuracy UVA PPK for DJ UVA Drone Mapping
Why loaded GPS PPK System for DJI Phantom 4 Pro Drone?
The DJI Phantom 4 Pro is already one of the most popular mapping drones available. It's low cost, high quality sensor with mechanical shutter, and its ease of use makes it the perfect aerial survey equipment for small mapping projects.
Adding the PPK GPS equipment will eliminate the need for ground control points when aerial surveying. This can save hours of field work, and eliminate the need for expensive survey equipment on each project. PPK GPS modifications for your DJI Phantom 4 is an inexpensive solution to your UAV mapping needs.
PPK is an adapter kit a Phantom 4 Pro/Advance. It is easily removed so you can still use your travel case. When P4 is taking a photo, meanwhile a time mark is recorded in the Gama log file. This position is free from shutter timing errors, lever-arm errors, and camera calibration errors
Specifiaction:
|
Mechanical |
Size |
60x50x15 mm |
|
Weight |
18g |
|
|
Operating T |
-30 ~+75 |
|
|
GNSS |
Signals |
GPS/QZSS L1 GLONASS G1 Beidou B1 Galileo E1 SBAS |
|
Tracking channels |
72 |
|
|
Update rate |
10Hz/5hz |
|
|
Electriacl |
Input voltage |
5V,8V-35V |
|
Antenna Dc |
5V |
|
|
Average Current consumption |
25mA |
|
|
Data |
storage |
16GB |
|
Data format |
Rinex |
|
|
Connetivity |
Antenna |
Mcx |
|
Interface |
Event ,TFcard |
|
|
Led |
Power,logging,SV,Event |
|
|
Positioning |
H |
2cm+1ppm |
|
V |
4cm+1ppm |
Survey Requirements:
Phantom 4 /Pro/Advance
RINEX capable base receiver
