Design hot sell ultrafine dry powder fire extinguishers

Specifications ultrafine dry powder fire extinguishers

1. Marine Fire Extinguisher

2. Competitive price extinguisher

3. Certificate :ES/CCS

Design hot sell ultrafine dry powder fire extinguishers       Product Description 1.Specification of ultrafine dry powder fire extinguishers:

Dry chemical powder extinguisher	MFZ/ABC1	MFZ/ABC2	MFZ/ABC3	MFZ/ABC4	MFZ/ABC5
Extinguisher classification	1A21B	1A21B	2A34B	2A55B	3A89B
Weight of extinguisher agent  (kg)	1±0.05	2±0.06	3±0.09	4±0.08	5±0.10
Nitrogen pressure (Mpa20 ±5°C)	1.20~0.12	1.20~0.12	1.20~0.12	1.20~0.12	1.20~0.12
Effective spray time (s)	8	8	13	13	13
Spary residual rate (%)	≤15	≤15	≤15	≤15	≤15
Delayed-action time of discharge(s)	≤5	≤5	≤5	≤5	≤5
Effective spray distance (m)	3	3	3.5	3.5	3.5
Application temperature (°C)	-20~+55	-20~+55	-20~+55	-20~+55	-20~+55



Model No.	SB01-04-1.3AS1	SB01-04-2AS1	SB01-04-2.3AS1	SB01-04-5AS2	SB01-04-6AS1	SB01-04-9AS1
Type	1.3kg	2kg (A)	2.3kg(A)	5kg (B)	6kg (A)	9kg (A)
Out Diameter (mm)	105	105	105	136	136	154
Height(mm)	335	450	520	585	760	870
Volume (L)	2+0.21	3+0.30	3.5+0.35	6.67+0.67	9.0+0.9	13.5+1.35
Min.Thickness(mm)	2.7	2.25	2.25	3.4	2.6	3
Material	34CrMo4	34CrMo4	34CrMo4	34CrMo4	34CrMo4	34CrMo4
Working Pressure (Bar)	167~174	167~174	167~174	167~174	167~174	167~174
Test Pressure(Bar)	250	250	250	250	250	250
Operating temp.	-30℃ to +60℃	-30℃ to +60℃	-30℃ to +60℃	-30℃ to +60℃	-30℃ to +60℃	-30℃ to +60℃
Fire rating	21B	34B	34B	89B	89B	144B
Extinguisher weight (kg)	4.15	6.05	7	14.1	16.7	22.8

  2.Introduction of ultrafine dry powder fire extinguishers: Starblaze is a total solution provider with his head office in Chongqing Starblaze Import&Export Co.,Ltd. We are the earliest professional exporter of marine fire-fighting equipment and offshore equipment since 1998 years. We have a professional international sales team to do the export business in the Global. With years of experience, We are able to provide value added services and qualified product in all marine fire-fighting industrial. We have good honor in this field. Our extinguisher has following features: 1) Simple structure, flexible operation, convenient application.   2) Fast extinguisher speed, high efficiency, continuous orintermittent spraying.   3) Applicable to the extinguishments of initial fires caused by oil, flammable liquids, solid organices, gas and electric equipment.   4) Ideal equipment for use in cars, offices, schools, hotels, restaurant.     3.Picture of ultrafine dry powder fire extinguishers:                       Company Information Service&Certificate of ultrafine dry powder fire extinguishers: We are quite flexiable on order qty, always offer our customer best price with the fastest shipment,the third party inspection like SGS,BV,TUV and accept customize standard and nonstandard products can be supplied. All of working staffs here are with year experience and expertise in steel industrial.we can controal quality throughout manufacturing,qaulity control,packing,delivery and transportation.       ultrafine dry powder fire extinguishers
