600kW 1260RPM Googol Oil Field Diesel Engine

1260rpm Googol PTAA1780DM2 DIesel Engine for Drilling Machine

Engine Model		PTAA1780-DM2
Speed	rpm	1260
Rating Output
Engine Prime Output	kW	607
Engine Prime Output	Hp	825
Engine Continuous Output	kW	551
Engine Continuous Output	Hp	750
BMEP for Prime Output	bar	20
BMEP for Continuous Output	bar	17.95
Fan Reduction	kW	30
Fan Reduction	Hp	41
Basic Performance Datasheet
Aspiration Type		Turbocharger, air-air aftercooler
Injection Type		Direct Injection
Configuration		Vee
No. of Cylinders		16
Displacement	l	29.2
Bore	mm	128
Stroke	mm	142
Compression Ratio		14.6:1
Piston Speed	m/s	5.964
Rotation Direction (from flywheel)		Counter Clockwise
Number of Flywheel Teeth		204
Flywheel House Size		SAE0-18
Cooling System
Coolant Capacity for Engine	l	26
Max. Permissible Temperature	°C	90
Max. Coolant Warning Temperature	°C	95
Max. Coolant Shutdown Temperature	°C	105
Thermostat Open Temperature	°C	71
Radiator Cooling Flow	(m³/min)	1386
Flow of Coolant pump	m³/h	44.00
Fuel System
Governor Type		Electrical
Engine Output at engine prime output	kW	607
Fuel Consumption at 100% of engine prime output	l/h	145.03
Lowest Fuel Consumption Ratio	g/kW.hr	194.15
Intake & Exhaust System
Combustion Air Consumption	m³/min	72.19
Max. Intake Restriction	KPa	2.5
Exhaust Temperature (Before Turbo)	°C	630
Exhaust Temperature (After Turbo)	°C	500
Max. Exhaust Back Pressure	KPa	2.5
Exhaust Gas Flow	m³/min	181.58
Exhaust Flange Diameter	mm	2*150
Engine Dimension
Length	mm	1950
Width	mm	1389
Height	mm	1162
Engine Dry Weight w/o Cooling System	kg	2450

    1. All engine parameters are in accordance with ISO3046, ISO8528.   2. All engine parameters are based on 25°C / 100kPa environment condition.         Standard scope of supply      Note: 1. All engine parameters are in accordance with ISO3046, ISO8528. 2. All engine parameters are based on 25°C / 100kPa environment condition. 3. Application for Power Generation, Marine, Pump Driving, CHP power plant.   Warranty:    All equipment is guaranteed for a period of 1000 hours running or 18 months from the date when the generator set has been delivered from the factory.   Company Profile:    GOOGOL Engine-Tech Co., Ltd. is a Leading manufacturer of US based latest technology. GOOGOL also set up Chongqing GOOGOL Engine-Tech Co., Ltd based in China.    Our Product Range is 230 KW to 2722 KW Diesel Engines, 160 KW to 1800 KW Gas Engines, 200 KW to 2400 KW Dual Fuel Engines with middle speed at 1000rpm, 1200rpm, and high speed at 1500rpm, 1800rpm
