Model | JK-ZZW |
Motor Type | Brushless DC Drum Brake hub motor |
Dimension (L×W×H) mm | 1720×630×120 |
Weight of the bicycle(Kg) | < 70Kg |
Load (Kg) | 200-250Kg |
Max speed (Km) | 25Km/h |
Distance per charge (Km) | 80Kms |
The distance between two wheels (mm)±20 | _1180_mm |
Tire specification (inches) | front 2.15″×18 、rear2.15″×18 |
Energy consumption per hundred kilometers (Kw/h) | ≤0.4 |
Type | Brushless big-drum brake motor |
40HQ(CKD) | 230PIC |
Rated output power (W) | 350w |
Rated voltage (V) | 48v |
Rated capacity of the lead acid cell (Ah) | 14Ah |
Charging time of the cell (h) | 6~8Hrs |
Under-voltage protection for the controller (V) | 42±1.5V |
Current limiting protection (A) | 17±1A |
Rated rotation speed (r/min) | 360±10 |
Rated torque (N.m) | 23N.m |
Climbing ability (°) | 10-12° Degrees |
Max noise (dB) | < 60dB |
Rated voltage of the motor (V) | 48v |
