Model | JK-SJLY |
Motor Type | Brushless DC Drum Brake hub motor |
Dimension (L×W×H) mm | 1720×740×1120 |
Weight of the bicycle(Kg) | <100Kg |
Load (Kg) | 120-150Kg |
Max speed (Km) | 35Km/h |
Distance per charge (Km) | 85/75Kms |
The distance between two wheels (mm)±20 | 1220 |
Tire specification (inches) | front 3.0″×16 、rear3.0″×16 |
Energy consumption per hundred kilometers (Kw/h) | ≤0.4 |
Type | Brushless big-drum brake motor |
40HQ (CKD) | 160PIC |
Rated output power (W) | 350w |
Rated voltage (V) | 48v |
Rated capacity of the lead acid cell (Ah) | 20Ah |
Charging time of the cell (h) | 6~8Hrs |
Under-voltage protection for the controller (V) | 42±1.5V |
Current limiting protection (A) | 17±1A |
Rated rotation speed (r/min) | 450±10 |
Rated torque (N.m) | 17N.m |
Climbing ability (°) | 10-15° Degrees |
Max noise (dB) | <60dB |
Rated voltage of the motor (V) | 48v |
