Specifications Electric Bicycle,new
Model | BS-QGM |
Motor Type | Brushless DC hub motor |
Dimension (L×W×H) mm | 1760×480×1060 |
Weight of the bicycle(Kg) | <100Kg |
Load (Kg) | 120-150Kg |
Max speed (Km) | 35Km/h |
Distance per charge (Km) | 80Kms |
The distance between two wheels (mm)±20 | _1200_mm |
Tire specification (inches) | 3.0-10 |
Energy consumption per hundred kilometers (Kw/h) | ≤ 0.4 |
Type | Brushless big-drum brake motor |
40HQ(CKD) | 155PIC |
Rated output power (W) | 350W |
Rated voltage (V) | 48v |
Charging time of the cell (h) | 6Hrs |
Under-voltage protection for the controller (V) | 42±1.5V |
Current limiting protection (A) | 23±1A |
Rated rotation speed (r/min) | 450±10 |
Rated torque (N.m) | 17N.m |
Climbing ability (°) | 10-12° Degrees |
Max noise (dB) | < 60dB |
Rated voltage of the motor (V) | 48v |
