Electric Tricycle for tourist

Specifications Electric Tricycle for tourist

Model: BS-YFQQ15

Moter:1100W 60V Speed: 30-40 KM/H

All those parameter can be change as you mee

Item Name:Electric Tricycle for tourist Item NO. BS-YFQQ15   PARAMETER:

Model	JK-YFQQ15	Rated output power (W)	1100w
Motor Type	brush motor	Rated voltage (V)	60v
brake mode	drum brake	Charging time  (h)	10-12Hrs
transmission	chain drive	charging voltage	110V-220V
Dimension (length x width x high) mm	3150*1050*1750mm	shocker	normal shock
Weight of the bicycle(Kg)	300kg	Climbing ability (°)	10-15 degree
Load (Kg)	350KG	Rated voltage of the motor (V)	60v
Max speed (Km)	30-40km/h	passenger quantity	5-6 passengers
Distance per charge (Km)	120KM	Tire specification (inches)	front 3.25-16、rear4.0-12
		battery type	60v120ah
40HQ container LOADING QTY(CKD)	40 sets by CKD condition	FOB SHANGHAI (without battery)	USD530.00
		battery 12V120AH(normal brand)	USD69.00/PC
		Total (Normal brand)	USD875.00
		Leike battery	USD78.00/PC
		Total (Leike A+B  battery)	USD920.00
		36V 100AH(Normal brand)	USD737.00







SIR/MADAM, please allow to introduce our company to kyou,

Bashan Group  is a multi-regional and the ownership of shareholding corporation dealing with the designing and production of motorcycles, electric bikes ,ATV, tricycles.



     Bashan has passed ISO9001:2000 certification, the brand motorcycle have got E-mark, EPA ,DOT and ADR certification and has made over 100 inventions and patents.

     The motorcycle production quantity is 500,000-600,000 pieces per year, and exported to more than 30 countries over the world.









Model	JK-GG3XF	Rated voltage (V)	48v
Motor Type	Series excitation	Charging time  (h)	4-8Hrs
brake mode	drum brake	charging voltage	AC 110V-230V
transmission	chain drive	Climbing ability (°)	9 degree
Dimension(length x width x high) mm	2450×1100×1730mm	Rated voltage of the motor (V)	48v
Weight of the bicycle(Kg)	215kg（without battery）	passenger quantity	3 passengers
Load (Kg)	300KG	Tire specification (inches)	front 4.0-12、rear4.0-12
Max speed (Km)	≤35km/h	battery type	48v120ah
Distance per charge (Km)	110KM	FOB SHANGHAI(without battery)
40HQ container LOADING QTY(CKD)	40 sets by CKD condition	battery 12V120AH(normal brand)
		36V 100AH(Normal brand)
		48V 120AH(Normal brand)
Model	BS-HBTX	Rated output power (W)	60V/1000W
Motor Type	DC series excitation	Rated voltage (V)	AC90-120V,50/60HZ,AC210-240V,50/60HZ
brake mode	drum brake	Charging time  (h)	8-12Hrs
transmission	chain drive	charging voltage	220V-240V
Dimension (length x width x high) mm	2900*1060*1850	shocker	NORMAL SHOCK
Weight of the bicycle(Kg)	394KG	Climbing ability (°)	20 degree
Load (Kg)	≤450kg	Rated voltage of the motor (V)	48v
Max speed (Km)	≤40-45km	passenger quantity	2-3 passengers
Distance per charge (Km)	≤130km	Tire specification (inches)	3.25-16   4.00-12
		battery type	5pcs of lead acid battery 12V/120AH
40HQ container LOADING QTY	22pcs/20"GP,46pcs/40"HQ	FOB SHANGHAI (without battery)
		battery 12V120AH(normal brand)
		Total (Normal brand)
		Leike battery
		Total (Leike A+B  battery)
		36V 100AH(Normal brand)
