GD-6536A Distillation Tester (Double Units)

Conforms standard:

GB/T6536 Test Method for Distillation Characteristics of Petroleum Products

ASTM D86 Standard Test Method of Distillation for Petroleum Products at Atmospheric Pressure.

it is suitable to determine the distillation characteristics of gasoline, aviation gasoline, jet fuels, solvent having special boiling point, naphtha, diesel oil, distillate fuels, and other petroleum products.

This atmospheric pressure oil distillation tester is not only suitable to the organizations of high frequency with various of samples but also accelerate the test speed for common users.

It is an ideal distillation tester for petroleum products.

I. Main Technical Features

1.The atmospheric pressure oil distillation tester adopts double units working mode, can do test for one sample as well as two samples which having the same specification or different specifications.It highly improves the work efficiency.

2.atmospheric pressure oil distillation tester adopts two groups of independent digital temperature controller, heater, electric stirrer to constitute two constant temperature baths. Each bath temperature can be adjusted and controlled independently.The temperature in the bath is uniform,can fully meet the requirements of test.

3. atmospheric pressure oil distillation tester adopts special heating furnace to ensure the safety of test. Heating power can be stepless adjusted to meet the requirements of test.

II. Main Technical Specifications

1.Power supply: AC(220±10%)V, 50Hz

2.Heating power: 1000W×2, continuously adjustable.

3.Receiving cylinder: 100ml, division value 1ml.

4.Distillation flask: 125ml,meet the requirements of GB/T 6536 and ASTM D86

5.Thermometer: (-2~300)℃ and (-2~400)℃, division value 1℃

6.Flask support board: SiC, bore diameter φ32mm, φ38mm, φ50mm.

7.Temperature controller:1) Control range: (room temperature+10)℃~60℃

2) Accuracy: ±0.5℃

3) Temperature display: LED

Note: The temperature control is to control the temperature of condensate in the condenser pipe.

8.Ambient temperature: ≤35℃

9.Relative humidity: ≤85%

10.Maximum power consumption: 2200W

11.Dimension:760mm×520mm×500mm
