GD-8019B Existent Gum Tester

1.GB/T 8019-2008 Standard test method for gum content in fuels by jet evaporation

2.ASTM D381Standard Test Method for Gum Content in Fuels by Jet Evaporation.

Summary

Existent Gum Tester can be used to determine the existent gum content of aviation fuels by steam vaporizing medium.

Fuel oil Existent Gum Tester Equips with an air compressor, this instrument can also be used to determine the existent gum content of aviation gasolines and motor gasolines by air vaporizing medium.

I. Main technical features

1. Fuel oil Existent Gum Tester equips a specially designed heating bath.The gas circuit is designed reasonably and the effect of

evaporation is good.

2. The material of working bench is stainless steel. It has 3 sample wells. A pressure gauge shows the

flow rate when steam vaporizing medium is used. A ball float type flowmeter shows the flow rate

when air vaporizing medium is used. It can determine 3 samples at a time.

3. The instrument is desktop structure. Simple design and easy to operate.

II. Main technical specifications

GD-8019B Gum content tester

1. Power supply:AC(220±10%)V,50Hz,2.5kW

2. Test wells: 3 wells

3. Operating temperature:

1) Test bath temperature is (232~246)℃ and test well temperature being (229~235)℃ for steam bath.

2) Test bath temperature is (160~165)℃ and test well temperature being (150~160)℃ for air bath.

4. Temperature control:Automatic

5. Temperature display:Digital

6. Flow display:Pressure gauge shows flow rate when steam vaporizing medium is used. Ball float

type flowmeter shows flow rate when air vaporizing medium is used.

7. Working pressure of air reducing valve:0.035MPa(for air vaporizing medium).

8. Gas source: Electrical heating steam generator for steam vaporizing medium. Air compressure for

air vaporizing medium, over (1000±150)ml/s.

9. Overall dimension:640mm×480mm×340mm(Thermometer holder is not included).
