JY-715 steel grandstand

      JY-715steel grandstand

PRODUCT PARAMETER
Brand	JUYI
Type	steel grandstand
Model No.	JY-715
Place of Origin	Chongqing
Customized or not	Yes
Size	Customer
General Use	School, TV Station Showroom , Stadium, race court, etc.
Description	5pcs chairs connect together, and each block chairs can be removed down to the platform, so that easy to remove the whole grand platform. The understructure is made by welded I beam steel with surface hot-galvanized. The tread is made by extruded aluminum with surface anodized. The riser is rolled by 2.0 galvanized steel belt with surface powder coated. The safety rail is made by welded square bar and flat bar with surface galvanized and powder coated. Blow molded plastic chair. The width of passage:1.2m Our projects including: 1.University gymnasium in Bangkok, Thailand   2. Indonesia stadium 3. French reunion telescopic bleachers
Packaging Details	CKD in carton
MOQ	500sets
Delivery Time	25-30 Days below 3000pcs
Output	5000sets/Month
Loading Port	Chongqing
Payment	T/T L/C

  Specifications

1.Dismountable Bleacher( 5 or more chairs attached to platform by antirust metal support structure)
2.All metal structure are steel and dealt with antirust,the floor is galvanized steel sheet.
3.The platform structure is Japanese style, stable triangular structure,assembled by modular parts, not need to weld.It can be assembled according to the dimension of the site.
4. Blow molding plastic seats,center distance:455-480mm
5.Width of platform deck: 800-900mm
6.Width of Passageway: 800-1000mm
7.Material of the chair: HDPE
8.Left, right, rear sides of safety railing included, Height: 1000mm
9.Chair color could be selected by client;
10.Step hight : 200mm
11.Volume of the bleacher for per seat:0.16CBM


MOQ:100 seats
Delivery Time:20-30 working days Payment Terms: T/T, L/C
Port of delivery:Chongqing,China
    telescopic case     Company Information Why us?                                              why us ? We are one of the leading professional manufacturers in this field,therefore we own the unique advantages as below cmpared to our competitors:     1.We do have done a lot of important projects,including  2016 FIFA U-20 World Cup, 2014 Olympic Winter Games in Russsa, 2008 Bei Jing Olympic Games press center hall;PLA General Armament Department Conference Hall.etc.       2.Providing best cost efficient products to our customers with stable quality and excellent after-sales service .    3.Fast delivery within 25-30days ,convenient and economic inland transportation.     4.More flexible payment terms for option,T/T,L/C etc.......     FAQ
