Double chamber 300N inflatable life jackets CCS certification

Double chamber 300N inflatable life jackets CCS certification

1. Performance and features

Inflatable life jackets fulfill the test and certification requirements according to the standard DIN EN ISO 12402-3.

The life jacket consists of one air chamber, which is made of nylon 210D oxford TPU composite material, an automatic inflation system including one CO2 cylinder, and an oral inflation tube. In emergency situation, when a person wearing the life jacket has fallen into water, the life jacket will be inflated by the automatic inflation system within 5 seconds. Additionally, it can be inflated by manually pulling the toggle, to ensure safety of the people at risk to drowning. When staying in water for a long time and finding the buoyancy not sufficient, please inflate the chamber additionally with the oral inflation tube.

The inflatable life jacket has the advantages of small size, light weight, comfort, easy use, and is suitable for offshore operation.

2. Main parameter

1) Body mass(kg): ≥60kg

2) Chest girth(cm): 94-140cm

3) Ambient temperature for use: -30℃ ~ +65℃

4) Inflation time: ≤5s

5) Freeboard: ≥100mm

6) Buoyancy: ≥150N

7) Gas: CO2

8) Gas content in cylinder: 33g

9) Self-weight: ≤1.1kg

<![if !supportLists]>10) <![endif]>Gas cylinder size: Φ25.4mm×138mm×1/2-20UNF
