NAKIN TYA Series Vacuum Lubricating Oil Filter Machine
Application
NAKIN TYA series vacuum lubricating oil filter machine is mainly for purifying unqualified lubricating oil, hydraulic oil, furnace oil, compressor oil, refrigeration oil and other industrial oils, this machine can rapidly separate water, gas, particles and volatile matter (such as alcohol, gasoline, ammonia, etc.) from lubricating oil, restoring oil viscosity, flash point and performance. The treated oil can reuse again in various industrial equipments. It is widely applied in petroleum, chemical, mining, metallurgy, electric power, transportation, machinery manufacturing, railway etc.
Features
1.Double primary-filter structure, large capacity for holding particles, multi-stage filtration system to ensure high filtration precision.
2. Special polymer materials as filter medium with the functions of broken emulsion, dewatering, removing particles.
3.Duplex-Stereo film evaporation technology, equips with unique and advanced dewatering, degassing components, can rapidly and effectively remove water, gas, particles and volatile matter (such as alcohol, gasoline, ammonia, etc.)
4. Automatic backwashing system, improving working efficiency.
5. Advanced medium cooling system.
6. High quality filtering components, large capacity for holding particles, anti-corrosion, good mechanical performance, long lifetime.
7. Efficient electric heating system, heating uniformity, less power consumption, safe, and reliable.
8. Adopts interlocked protective system, which connect oil pump, heater and liquid level sensor, avoiding blank heating, blank pumping, oil leak and electricity leak. If there is any fault, machine will be power off automatically.
Advantages
Good economic benefits, widely application, it is suitable for purifying various old lube oil in petroleum, chemical, mining, metallurgy, electric power, transportation, machinery manufacturing, railway and so on.
Technical Parameters
|
Index name |
Unit |
TYA-10 |
TYA-20 |
TYA-30 |
TYA-50 |
TYA-100 |
TYA-150 |
TYA-200 |
TYA-300 |
|
|
Flow rate |
L/H |
600 |
1200 |
1800 |
3000 |
6000 |
9000 |
12000 |
18000 |
|
|
Working vacuum |
MPa |
-0.06~-0.095 |
||||||||
|
Working pressure |
MPa |
≤ 0.4 |
||||||||
|
Temperature range |
℃ |
20 ~80 |
||||||||
|
Demulsifying value |
min |
≤15/min(GB/F7035) |
||||||||
|
Water content |
ppm |
≤100 |
||||||||
|
Gas content |
% |
≤ 0.1 |
||||||||
|
Cleanness |
|
≤ NAS 6 grade |
||||||||
|
Power supply |
|
380V 50HZ 3Ph (As per user`s option) |
||||||||
|
Working noise |
dB(A) |
≤65~80 |
||||||||
|
Heating power |
Kw |
24 |
24 |
30 |
40 |
60 |
90 |
145 |
160 |
|
|
Total power |
Kw |
27 |
27 |
33.5 |
44 |
65 |
97 |
157 |
178 |
|
|
Inlet(Outlet) |
mm |
Φ25 |
Φ25 |
Φ25 |
Φ32 |
Φ42 |
Φ50 |
Φ50 |
Φ60 |
|
|
Weight |
kg |
350 |
380 |
400 |
450 |
750 |
880 |
1100 |
1300 |
|
|
Dimension |
L |
mm |
1500 |
1500 |
1500 |
1600 |
1750 |
1900 |
1950 |
2100 |
|
W |
mm |
1000 |
1050 |
1050 |
1150 |
1150 |
1600 |
1600 |
1700 |
|
|
H |
mm |
1600 |
1600 |
1650 |
1700 |
1750 |
1950 |
1950 |
1950 |
|
