China online-turbine oil purifier, oil treatment
- Payment Type:
- T/T, L/C
- Incoterm:
- FOB
- Min. Order:
- 1 Set/Sets
- Min. Order:
- 1 Set/Sets
- Delivery Time:
- 15 Days
- Transportation:
- Ocean, Air
Your message must be between 20 to 2000 characters
Contact Now| Place of Origin: | Chongqing |
|---|---|
| Productivity: | 1000 sets per year |
| Supply Ability: | 1000 sets per year |
| Payment Type: | T/T,L/C |
| Incoterm: | FOB |
| Certificate: | ISO9001,CE |
| Transportation: | Ocean,Air |
Application:
Turbine oil is widely applied in industries, TY
vacuum turbine oil purifier is mainly used for purifying unqualified turbine oil,
especially for serious emulsion turbine oil, it can quickly and efficiently demulsify,
separate water, gas, particles from oil, make sure quality of treated oil to achieve new
oil's standard, ensure whole turbine system work safely. This equipment use the special
polymer materials as filter medium combined with vacuum separating technology
to break emulsification, dewater, degas, remove acid and particles, make the
badly turbid turbine oil becomes clear transparent. Series TY is a perfect
turbine oil purifier for live line work; also it can purify low viscosity
hydraulic oil and lube oil.
Features:
1. Special polymer materials as filter medium with the functions of broken emulsion, dewatering, removing particles
2. Duplex-Stereo film evaporation technology, equips with unique and advanced dewatering, degassing components, can rapidly and effectively separate water, gas from oil.
3. Multi-stage precision filtration system, mesh filtration combined with molecular adsorption technology.
4. Efficient electric heating system, heating uniformity, less power consumption, safe, and reliable.
5. Double-infrared liquid level sensor, pressure protective system to ensure machine operation easy and safely.
6. Adopt interlocked protective system, which connect oil pump, heater and liquid level sensor, avoiding blank heating, blank pumping, oil leak and electricity leak. If there is any fault, machine will be power off automatically.
7. Work online with stream turbine, hydraulic
turbine.
Technical Parameters:
Index Name
Unit
TY-10
TY-20
TY-30
TY-50
TY-100
TY-150
TY-200
TY-300
Flow rate
L/H
600
1200
1800
3000
6000
9000
12000
18000
Working vacuum
MPa
-0.06~-0.095
Working pressure
MPa
< 0.4
Temperature range
C
20 ~80
Demulsifying value
min
<15/min(GB/F7035)
Water content
ppm
< 80
Gas content
%
< 0.1
Cleanness
< NAS 6 grade
Power supply
380V 50HZ 3Ph (As per
user's option)
Working noise
dB(A)
<65~80
Heating power
Kw
24
24
24
30
45
60
72
84
Total power
Kw
27
27
27
33
48
66
81
97
Inlet(Outlet)
mm
25
25
25
32
42
50
50
60
Weight
kg
400
450
500
600
800
1000
1100
1550
