China vacuum lube oil purifier, oil purification machine
- Payment Type:
- T/T, L/C
- Incoterm:
- FOB
- Min. Order:
- 1 Set/Sets
- Min. Order:
- 1 Set/Sets
- Delivery Time:
- 15 Days
- Transportation:
- Ocean, Air
Your message must be between 20 to 2000 characters
Contact Now| Place of Origin: | Chongqing |
|---|---|
| Productivity: | 1000 sets per year |
| Supply Ability: | 1000 sets per year |
| Payment Type: | T/T,L/C |
| Incoterm: | FOB |
| Certificate: | ISO9001,CE |
| Transportation: | Ocean,Air |
Application:
Thousands ton dirty, waste lube oil need to purify per day. TYA Lubricating oil purifier machine is widely applied in industries; which is special for purifying unqualified, waste, dirty lubricating oil, hydraulic oil, compressor oil, refrigeration oil etc. it can effectively demulsify waste oil, separate water, gas, particles and volatile matter (such as alcohol, gasoline, ammonia, etc.) from oil, restoring oil`s performance, like the performance, flash point etc. Treated oil can reuse again in various industrial equipments.
Features:
1. Double primary-filter structure, large capacity for holding particles, Multi-stage filtration system to ensure high filtration precision.
2. Special polymer materials as filter medium with the functions of demulsifying, dewatering, removing particles
3.Oil film sprayer and evaporation technology, equips with unique and advanced dewatering, degassing components, can rapidly and effectively remove water, gas and volatile matter (such as alcohol, gasoline, ammonia, etc.)
4. Automatic backwashing system, improving working efficiency
5. Advanced medium cooling system
6. High quality filtering components, large capacity for holding particles, anti-corrosion, good mechanical performance, long lifetime.
7. Efficient electric heating system, heating uniformity, less power consumption, safe, and reliable.
8. Adopts interlocked protective system, which connect oil pump, heater and
liquid level sensor, avoiding blank heating, blank pumping, oil leak and
electricity leak. If there is any fault, machine will be power off
automatically.
Technical Parameters:
|
Index name |
Unit |
TYA-10 |
TYA-20 |
TYA-30 |
TYA-50 |
TYA-100 |
TYA-150 |
TYA-200 |
TYA-300 |
|
Flow rate |
L/H |
600 |
1200 |
1800 |
3000 |
6000 |
9000 |
12000 |
18000 |
|
Working vacuum |
MPa |
-0.06 to -0.095 |
|||||||
|
Working pressure |
MPa |
≤ 0.4 |
|||||||
|
Temperature range |
C |
20 to 80 |
|||||||
|
Demulsifying value |
min |
≤15/min(GB/F7035) |
|||||||
|
Water content |
ppm |
≤100 |
|||||||
|
Gas content |
% |
≤ 0.1 |
|||||||
|
Cleanness |
|
≤ NAS 6 grade |
|||||||
|
Power supply |
|
380V 50HZ 3Ph (As per user's option) |
|||||||
|
Working noise |
dB(A) |
≤65 to 80 |
|||||||
|
Heating power |
Kw |
24 |
24 |
30 |
40 |
60 |
90 |
145 |
160 |
|
Total power |
Kw |
27 |
27 |
33.5 |
44 |
65 |
97 |
157 |
178 |
|
Inlet(Outlet) |
mm |
Φ25 |
Φ25 |
Φ25 |
Φ32 |
Φ42 |
Φ50 |
Φ50 |
Φ60 |
|
Weight |
kg |
350 |
380 |
400 |
450 |
750 |
880 |
1100 |
1300 |
