High Quality Miniature Circuit Breaker Price
-
USD7≥1000 Set/Sets
- Payment Type:
- L/C, T/T, D/P
- Incoterm:
- FOB, CFR, CIF
- Min. Order:
- 1000 Set/Sets
- Min. Order:
- 1000 Set/Sets
- Transportation:
- Ocean
- Port:
- Chongqing, Shanghai
Your message must be between 20 to 2000 characters
Contact Now| Supply Ability: | 1000 Sets /years |
|---|---|
| Payment Type: | L/C,T/T,D/P |
| Incoterm: | FOB,CFR,CIF |
| Transportation: | Ocean |
| Port: | Chongqing,Shanghai |
Packaging Details :Standard Export Package.Also can be customized according to buyer's requirement.
Delivery Time 1-2 weeks after payment
High Quality Miniature Circuit Breaker Price
This RDX30LE residual circuit breaker is Integrated ,minitype ,1p+N current leakage protection circuit .it used in circuit of AC 50Hz/60Hz ,rated working voltage 230V ,rated current 40A proection distribution xircuit it has the overload protection for the building circuit or other similar circuit. And it hase the powerful auxiliary function module, like auxiliary contact, alarm indication contact, shunt and underlvoltage release, remote release control.
Main technical parameter
| Poles | 1P,2P,3P,1P+N |
| Rated Current | 6A,10A,16A ,20A 25A,32A |
| standard | GB16917 |
| Rated voltage | 230V |
| Rated Residual operating current | 30mA, |
| Residual operating current |
30mA, 100mA, 300mA |
Operating condition
1 Ambient temperature: -5℃~ +40℃; Average value in 24h does not exceed +35℃.
2 Altitude height of Installation places does not exceed 2000m.
3 Condition of atmosphere
When it is the highest temperature +40℃, the relative humidity does not exceed 50%, and it allows a certain high relative humidity when it is at relatively low temperature. For example, it reaches 90% when 20℃, and it should take special measurements when there occurring condensation due to the temperature variation.
4 Pollution grade: 2, 3
5 Installation condition: Installing at the places that without obvious impact and vibration, as well as the medium without danger (explosion).
We devote ourselves to offering humanized serving for each customer! No matter the business is big or small, we are always doing our best to offer our best services to our customers, and developing together
1. strict quality control inspection before shipment
2. shockproof & high quality blister packing to protect the item from damaging during shipment
3. OEM design & OEM packing welcome
4. Strong production ability
5. Service online,reply to you within 6 hours
