Mobile Self-loading Concrete Mixer

Portable Millstone Type Concrete Mixer can be used for different projects and a solution to many problems. The most important aspect that a Mobile Concrete Mixer can bring is the flexibility of always having fresh concrete on site by the time you need it.

The concrete is fresh and maximum strength every time, comparing the output of a volumetric concrete mixer with a traditional ready mix.  Concrete produced by mobile concrete mixers meets standards established by ASTM 685 and AASHTO M-241 standards as well as DOT requirements.

The efficient retating concrete  mixer , drum type is normal used , which is  just need one operator to drive, load, and mix raw material while moving it. Mobile Concrete Mixer has a higher working efficiency, higher mixing effect. At the same time, it greatly reduces the labor cost and working time.

Loading: Because of hydraulic shovel, this mixer can load the material easily and accurately. Inside blade can tear the cement bag to avoid material waste.

Mixing : After the aggregate and cement are fed into the mixing barrel, they will be mixed with the pressed water from the double water tanks which are on the truck. The specially designed double screw to confirm the quality of concrete;

Transport: This mixer is fit for any working site because of its 4 wheel hydraulic drive system and favorable configuration. Also mixing during towing. It can crawl on the 35 degree slope at a full load situation;

Driving cab: There is a well appointed cab. The driver can operate almost all the actions through a handle shank.

Brake: Disc brake system for safe working.

Type:

Drum Type Mobile Concrete Mixer is available for sale

Off-road concrete mixer Technical Parameter:

Engine Model: Quancai 490

Rated speed: 2400ram

Engine power: 38kw

Max output torque: 3600n/m

Hydraulic system flow: 42-63ml/r

Hydraulic rated pressure: 16mpa

Max turing radius: 20degree

Max working slope: 35 degree

Max towing speed: 20km/h

Max loaded volume: 1CBM

Feeding funnel raise time: ≤4sec

Feeding funnel fall time: ≤3sec

Mixer diameter: 1700mm

Mix full drum time: ≤ 2min

discharge height: 800mm

Cab configuration: standard

Tire spec: 14/90-16

Brake configuration: disc brake

Guide chute: equipped

Total weight: 4200kgs

Dimension: 5000*1980*2750mm

Warranty: 1 year

OEM: Accepted

Pre-sales Service

* Inquiry and consulting support.

*Sample testing support.

*View our factory.

After-sales Service

*Training how to install the machine, how to use the machine.

CHONGQING Honggong Construction MACHINERY Co.,ltd specializes in the design, production and sale of highway guardrail Pile extractor, Automatic Pile Driver, multi- Functional Highway Guardrail Pile Driver, Drum Type mobile Concrete Mixer, mobile Concrete Mixer and other series of equipment, at the lowest and most affordable price to sell, welcome to come to negotiate.
