Drum Mobile self-loading Beton Mixer
  • Drum Mobile self-loading Beton Mixer
  • Drum Mobile self-loading Beton Mixer
  • Drum Mobile self-loading Beton Mixer
Drum Mobile self-loading Beton Mixer
Drum Mobile self-loading Beton Mixer
Drum Mobile self-loading Beton Mixer

Drum Mobile self-loading Beton Mixer

Payment Type:
T/T
Incoterm:
FOB, CIF
Min. Order:
1 Set/Sets
Min. Order:
1 Set/Sets
Delivery Time:
10 Days
Transportation:
Ocean, Land
Port:
ChongQing, ShangHai
Quantity:

Your message must be between 20 to 2000 characters

Contact Now
Basic Info
Basic Info
Place of Origin: ChinaQing, China
Payment Type: T/T
Incoterm: FOB,CIF
Certificate: ISO9001
HS Code: 8474310000
Transportation: Ocean,Land
Port: ChongQing,ShangHai
Product Description
Product Description

Drum type mobile concrete mixer, mobile diesel concrete mixer , the drum on the tractor to keep on mixing during transportation to avoid soliditication of the concrete.  Other than size and the amount of space required to maintain a mobile mixer, the portable equipment can beat other traditional drum mixers, as it can get to many places and the concrete mix can be changed easily.Off-road Wheeled Mobile Beton Mixer

The efficient mobile diesel concrete mixer just need one operator to drive, load, and mix raw material while moving it. It has a higher working efficiency, higher mixing effect. At the same time, it greatly reduces the labor cost and working time.

Loading: Because of hydraulic shovel, this mixer can load the material easily and accurately. Inside blade can tear the cement bag to avoid material waste.

Mixing : After the aggregate and cement are fed into the mixing barrel, they will be mixed with the pressed water from the double water tanks which are on the truck. The specially designed double screw to confirm the quality of concrete;

Transport: This mixer is fit for any working site because of its 4 wheel hydraulic drive system and favorable configuration. Also mixing during towing. It can crawl on the 35 degree slope at a full load situation;

Driving cab: There is a well appointed cab. The driver can operate almost all the actions through a handle shank.

Brake: Disc brake system for safe working.

Type: drum type concrete mixer is available for sale



Drum type mobile concrete mixer Technical Parameter:

Engine Model: Quancai 490

Rated speed: 2400ram

Engine power: 38kw

Max output torque: 3600n/m

Hydraulic system flow: 42-63ml/r

Hydraulic rated pressure: 16mpa

Max turing radius: 20degree

Max working slope: 35 degree

Max towing speed: 20km/h

Max loaded volume: 1CBM

Feeding funnel raise time: ≤4sec

Feeding funnel fall time: ≤3sec

Mixer diameter: 1700mm

Mix full drum time: ≤ 2 min

discharge height: 800mm

Cab configuration: standard

Tire spec: 14/90-16

Brake configuration: disc brake

Guide chute: equipped

Total weight: 4200kgs

Dimension: 5000*1980*2750mm

Warranty: 1 year

OEM: Accepted



Pre-sales Service

* Inquiry and consulting support.

*Sample testing support.

*View our factory.



After-sales Service

*Training how to install the machine, how to use the machine.
