Basic Info

Place of Origin:	chongqing,China
Productivity:	1 set per day
Payment Type:	L/C,T/T,Western Union
Incoterm:	FOB,CFR,CIF,EXW
HS Code:	8421
Transportation:	Ocean,Air
Port:	Shanghai,Chongqing,Guangzhou

Product Description

Application:

Our COP edible oil recycle purifier is specially used to purify different edible oil such as cooking oil,vegetable oil,olive oil, palm oil,coconut oil, etc. It could remove color,offensive smell,water,particles,alcohol,acid out from used oil or food grade crude oil.

It is also suitable for treating used cooking oil before making it into biodiesel.

Brief Introduction:

This machine adopts Plate Pressure system can separate the sundry goods and water from the oil quickly and effectively. Then superadded two primaries filter and fine filter, it can remove impurities thoroughly. Next, the machine adopts highly vacuum system to dewater and deodorize. In addition, this machine use stainless steel filter element, it resists the acid in oil strongly. So, the used cooking oil was recycled by machine, it will become limpidity, and fresh quality.

Features and Advantages:

1. Highly effective vacuum dewater, deodorize, and eliminate impurities system.
2. It adopts Plate pressure system with the strong ability to filter the impurity, which can filter the particles and impurities completely.
3. It has the back flush system, which can clear impurities automatically.
4. We uses stainless steel filter element which has a good function in anti-corrosive. Especially, the precision of eliminates impurity is high and the service life is long. Also, it has a large volume for storing the impurities.
5. The unique degas and dewater system: Using the 3D-Evaporation technical and thin film evaporation, which can separate the trace water, soluble water and gas from the oil quickly by the Multi-level water-oil separation technology.
6. Hi-automatization operation, convenience, reliable, and safety.

Advantages:
5~10 years quality guarantee
Brand parts of Siemens, Schneider etc.
Safe, Anti-explosion design
Full-automatic, no need worker presence
Environmental, equips exhaust treatment device
High recovery, no waste of energy

Technical Data:

Item	Unit	COP-10 l/minute	COP-20 l/minute	COP-30 l/minute	COP-50 l/minute	COP-100 l/minute	COP-150 l/minute	COP-200 l/minute	COP-300 l/minute
Vacuum degree	Mpa	-0.06 ~- 0.095
Working pressure	Mpa	≤0.4
Temperature range	℃	0~100 adjustable depend on oil type
Working noise	dB(A)	≤75	≤75	≤75	≤78	≤78	≤78	≤80	≤82
Heating power	KW	36	40	45	60	90	120	180	195
Total power	KW	38	42	47	65	96	127	197	217
Inlet/outlet caliber	mm	25	25	25	32	42	50	50	60
Dimension	m	1.71.151.7	1.751.151.75	1.81.21.75	1.851.31.85	1.91.51.9	1.91.72.0	2.11.72.1	2.21.72.2
Weight	kg	450	550	600	750	850	1000	1200	1500
Demulsification value	min	≤15
Power supply		380V 50HZ 3Phase(or as customer request)
Water content	PPM	≤50
Particles	μm	≤1~5 without free carbon
Cleanness	NAS	≤6 Grade(NAS1638)

We can customize for you:

Brand parts of Siemens, Schneider etc .
Anti-explosion design for flammable industrial environment.
Machine size design if you have special request.
Color as your preference.
Smaller model insulating oil purifier.
Just tell me if you have any other request!
