HOPU Stainless Steel Vacuum Hydraulic Oil Purifier

Application:

The machine widely suitable for electric power, metallurgy, mine, machinery, chemical industry, transportation, manufacture and food industry etc. and it is particularly used to recover and regenerate all kinds of high precision lubricating oil, including unqualified hydraulic oil, gear oil, refrigerator oil, pressure dissolving machine oil, heat treatment oil anti-rubbing hydraulic oil and so on.

Features:

1.Effectively remove the iron, flake, dust, impurities, water and organic substance from the inferior oil. Moreover, it can eliminate organic and inorganic acid to recover the performance of hydraulic oil.

2.Strong demulsifying capability, which could easy to separate the massive moisture contents, also easy to get rid of the little tiny water from oil.

3.Adopt high precision and stainless steel FH rectangle filtration system that import from Japan, the precision of filter can reach up to 1 micron.

4.Utilize Tongruis own invented technology of H, P, M macromolecule material, which can reduce 1 or 2 color code of oil, the machine especially fit to high viscosity lubricant oil, freezing machine oil, hydraulic oil and gear oil etc.

Working principe& flow chart:

1, Working principle

When the oil purification starts, firstly contaminated oil enter into heater, secondly flowed into pre-filter under the difference pressure, in which the large impurities are removed. Thirdly oil goes into intermediate filter. Fourthly oil flow into water separator, the water separator adopts a special skill which changes the change the impaction of oil and water

to speed up trace water and coagulate big water which is separated from oil and stored in water content. After that, oil passes through the fine filter and fine particles of matters is

removed during the process. Finally oil flows into vacuum pump which use stereo-evaporation removing residual trace of water and steam is condensed in the condenser or expelled out by the vacuum system. the oil was transported out by oil pump. The purification process has finished.

Technical parameter

We also supply other models:
