Mobil Lubricant Oil Filtration Dehydration Machines

Mobil Lubricant Oil Filtration Machines, Lube Oil Filter Equipment, Mobil Gear Oil Purifier , filter supliers in China



1. The model TYA is widely used in fields of mechanism, metallurgy, mine, petroleum, chemical etc.
2. The unit can purify various kinds of lubricants as hydraulic oil, machinery oil, coolant oil, refrigerator oil, gear oil, gasoline engine oil, diesel engine oil, thermal oil, mazut etc.
3. The unit can quickly remove free and dissolved water, trace water, gases, impurities and volatile matter like ammonia gases.Therefore, the quality of lubricating fluids can be fully recovered and perfect working performance can be totally guaranteed.

Characteristic

1. With strong impurities filtration ability and large-area, mass and deep precision filtration material can remove the tiny and fine impurities from used lubricants. With PM filter can filter off ferreous impurities.
2. Unique degassing and dewatering system, adopts mature film evaporation and 3D flash distillation technology, and multi-stage oil water separating technology, can quickly remove free and dissolved water and gases.
3. Electrical heating device is the optimized pipeline design, to ensure the unique heating and stable oil temperature.
4. Automatic constant temperature control device, automatic liquid level control device, automatic defoaming device, automatic pressure protection device and excellent configuration can ensure the equipment in high performance.
5. Work online with unattended operation and the indicator lights display the running status.
6. The complete unit adopts the safety interlock device. The discharge oil pump, vacuum pump are interlock to the heating device to avoid adverse effect of misuse.
7. Compact design, low noise, easy operation, longtime free maintenance, low power consumption, running cost saving.

Technical Parameters:

Index name		Unit	TYA-10	TYA-20	TYA-30	TYA-50	TYA-100	TYA-150	TYA-200	TYA-300
Flow rate		L/H	600	1200	1800	3000	6000	9000	12000	18000
Working vacuum		MPa	-0.06~-0.095
Working pressure		MPa	≤ 0.4
Temperature range		℃	20 ~80
Demulsifying value		min	≤10/min(GB/F7035)
Water content		ppm	≤20
Gas content		%	≤ 0.1
Cleanness			≤ NAS 4 grade
Power supply			380V 50HZ 3Ph (As per user`s option)
Working noise		dB(A)	≤65~80
Heating power		Kw	24	24	30	40	60	90	145	160
Total power		Kw	27	27	33.5	44	65	97	157	178
Inlet(Outlet)		mm	Φ25	Φ25	Φ25	Φ32	Φ42	Φ50	Φ50	Φ60
Weight		kg	350	380	400	450	750	880	1100	1300
Dimension	L	mm	1500	1500	1500	1600	1750	1900	1950	2100
	W	mm	1000	1050	1050	1150	1150	1600	1600	1700
	H	mm	1600	1600	1650	1700	1750	1950	1950	1950
