Product Description
DENEVO 1MP series (2MP CCTV Camera Basic Series )CCTV cameras are disigned as economical production with high cost perfomance. They are used widely in all kinds of fields such as school ,road ,hotel,hospital, shop and so on.
This series include popular bullet,box ,dome camera types and offer 8 configurations for user’s different requires.
DH-IPC-HFW1225B
DH-IPC-HFW1220B
DH-IPC-HFW1225D
DH-IPC-HFW1220D
DH-IPC-HDW1225C
DH-IPC-HDW1220C
DH-IPC-HDBW1020R
DH-IPC-HDBW1025R
The prduct features as below
1. Maximum frame rate output reach to 1 million (1280*720) 30fps.
2.1MP Series CCTV cameras take 1/4 inch COMS sensor,can get clearer images in low-light conditions.
3. 1MP Series CCTV cameras support H264 coding ,with feature of high compression ratio and low steam.
4.Maximum IR distance can reach to 50M.
5.Support corridor mode,WDR,3DNR,HLC,BLC,digtal watermaking encryption, suitbale for different surveillance envrioment.
6.Support ROI ,SMART H.264,can encode flexibly,apply to different bandwidth and storage.
7.Support DC12V/POE power supply, easy to engineering mount.
8.Support IP67 ingrees protection.
Specifications
| DH-IPC-HDW1225C/DH-IPC-HDW1220C | |
| Image Sensor | 1/3"CMOS |
| Effective Pixels | 2MP |
| Ajust Angle | Pan l0°～360°;tilt:0°～78°;Rotation 0°～360° |
| LED | 1 |
| Electronic Shutter Speed | Auto/Manual 1s~1/100000s |
| Minimum Illumination | 0.01Lux(Color);0.001Lux(BW);0Lux（OLUX） |
| Maxmium Infrated Range | 50M |
| Day/Night | IR-CUT Auto |
| Scanning System | Progressive |
| Noise Reduction | 3D DNR |
| Wide Dynamice Range | Support |
| Signal to Noise Ratio | >56dB |
| Gain Control | Auto/Manual |
| White Balance | Auto/Manual |
| Backlight Compensation Mode (BLD) | Support, Zone optional |
| HLC | Support |
| Focal Length | 2.8mm/3.6mm/6mm |
| Lens Interface | M12 |
| Lens Aperture |
F2.1/F2.1/F2.0 |
| Aperture Type | Fixed |
| Lens Type | Fixed |
| Field of View | 2.8mm:106*59 |
| 3.6mm:84*47 | |
| 6mm：51*30 | |
| Video Coding Standards | H.264;H.264H;H.264B;MJPEG |
| Bit Rate |
"H.264:7Kbps～8Mbps MJPEG:10Kbps～2Mbps" |
| Frame Rate | 50Hz:Main Steam (1280*720@25fps);Sub Steam(704×576@25fps)； |
| 60Hz:Main Steam(1280*720@30fps);Sub Steam(704×480@30fps) | |
| Default Stream at Default Resolution | 4M |
| Abnormality Detection | Support dynamic Detection ;Occlusion Detection;Network disconnection;IP Conflict;Unauthorized Access |
| Image Settings | Brightness; Contrast; Sharpness. Saturation; Gamma |
| OSD Superposition | Time;Channel;Location;Picture |
| Mirror | Support |
| Reverse Image | Support |
| Heartbeat Mechanism | Support |
| Record | Manual;Detection;Timing Priority Manual>Detection>Timing |
| Edage Storage | NAS;FTP;IMOU |
| Max. Users Access | 20 |
| Restore Default | One-click Restore |
| Web Viewer | IE7;IE8;IE9;IE10;Chrome8+;Firefox3.5+;Safari5+ |
| User Management | Support Max 20 Users,Multi-levels User Administration |
| Safe Mode | Authorised User and Password;MAC Address Binding;HTTPS Encrytion;IEEE 802.1x;NAC |
| AI | Support Dynamic Detection ,Occlusion Detection ,Scene-change Detection |
| Privcy Masking | Off/On (4 Zone Rectangle) |
| Corridor Mode | Support |
| Network Interface | 1;10/100M Ethernet Interface |
| Protocol | HTTP;TCP;ARP;RTSP;RTP;UDP;SMTP;FTP;DHCP;DNS;DDNS;IPv4/v6;QoS;UPnP;NTP;Bonjour;802.13x;Multicast |
| Interoperability | ONVIF;GB/T28181;CGI;PSIA;Imou |
| Power Supply | DC12V+POE（1225 Does not Support POE） |
| Power Consumption | Normal value 1.5W, Maximum value 3.9W |
| Operating Conditions | ﹣30℃～﹢60℃ |
| Operating Humidity | ≤95% |
| Ingress Protection | IP67 |
| Casing | Metal and Plastic |
| Dimensions |
φ110mm×95mm |
| Net Weight | 320g |
| Installation | Wall Mount;Ceilling Mount;Column Mount |
