H.265 2HDD 10ch PSE NVRTC-R3210
- Payment Type:
- L/C, D/P, Paypal, Money Gram, Western Union
- Incoterm:
- FOB, CFR, CIF, EXW, FCA
- Min. Order:
- 5 Set/Sets
- Min. Order:
- 5 Set/Sets
- Delivery Time:
- 15 Days
- Transportation:
- Ocean, Land, Air
- Port:
- Shenzhen, Tianjin, Shanghai
Your message must be between 20 to 2000 characters
Contact Now| Place of Origin: | Tianjin |
|---|---|
| Productivity: | 50000 sets per week |
| Supply Ability: | 200000 per month |
| Payment Type: | L/C,D/P,Paypal,Money Gram,Western Union |
| Incoterm: | FOB,CFR,CIF,EXW,FCA |
| Certificate: | ISO9001 CE FCC SGS |
| HS Code: | 85299049 |
| Transportation: | Ocean,Land,Air |
| Port: | Shenzhen,Tianjin,Shanghai |
Features
HD Input
• Plug and play
• S+265/H.265/H.264 video formats
• Connectable to the third-party network cameras
• Up to 10-channel input
• 8 PoE ports
• Supports live view, storage, and playback of the connected camera at up to 8MP resolution
HD Output
• 1×HDMI and 1×VGA simultaneous outputs
• HDMI Video output at up to 4K (3840 × 2160) resolution
HD Storage
• 2 SATA interfaces, up to 10TB for each HDD
• S+265 compression effectively reduces the storage space and costs by up to 75%
HD Transmission
• 1×RJ45 self-adaptive 10/100 Mbps network interface
• PoE Port: 8×RJ45 self-adaptive 10/100 Mbps network interfaceS
Various Applications
• Centralized management of IP cameras, including configuration, information import/export, real-time information display, upgrade, etc.
• Connectable to smart IP cameras from Tiandy and the recording, playing back, and backing up of VCA alarms can be realized
• VCA detection alarm is supported
• Smart search for the selected area in the video and smart playback to improve the playback efficiency
• Web6 supports plug-in-free browsing and can preview videos on all browsers
• Support cloud upgrade
• Support 250m long-distance transmission
Product Details
Specifications
HDMI: 1-ch, 3840×2160, 2560×1600, 2560×1440, 1920×1080, 1280×720, 800 ×600, 1024×768,
1366×768, 1440×900, 1280×800
English, Russian, Spanish, Korean, Italian, Turkish, Simple Chinese, Traditional Chinese, Thai, French
, Polish, Dutch, Hebraism (UI), Farsi (UI)
Input TC-R3210 /P
Video Input
10-ch
Max Resolution
8MP
Two-way Audio Input
1-ch, 3.5mm
Bandwidth
Income 80Mbps; Outcome 80Mbps
Output
HDMI/VGA Output
VGA:1-ch, 1920×1080, 1280×720, 800×600,1024×768, 1366×768, 1440×900, 1280×800
Screen Split
1/3/4/6/8/9/10
Audio Output
1×RCA
Decoding
Decoding Format
S+265/H.265/H.264
Recording Resolution
8MP/6MP/5MP/3MP/1080P/UXGA/720P/VGA/4CIF/DCIF/2CIF/CIF/QCIF
Preview Capability
1×4K, 1×5MP, 2×4MP, 4×1080P, 8×720P, 10×4CIF
Synchronous Playback
1×4K, 1×5MP, 2×4MP, 4×1080P, 8×720P
Records Encryption
Yes
Hard Disk
SATA
2 SATA interfaces for 2 HDDs
Capacity
Up to 10TB for each HDD
eSATA Interface
N/A
Array Type
N/A
External Interface
Network Interface
1xRJ45 self-adaptive 10/100 Mbps network interface
USB Interface
2×USB 2.0
Serial Interface
N/A
Alarm In/Out
0/1
POE
POE Interface
8×RJ45 self-adaptive 10/100 Mbps network interface
Power per POE Port
30W
Max Current per POE Port
600mA
General
Web Version
Web6
Language
Operating Conditions
-10℃～55℃, 10%~90% RH
Power Supply
100~240V AC, 50~60 Hz
Consumption (without HDD)
≤25W (without HDD)
Chassis
1U
Dimensions
45.1×255×231 mm (1.78×10.04×9.09 inch)
Weight (without HDD)
2.85Kg (6.28lb)
Related Products
TC-R3105 PoE
TC-R3210 PoE
TC-R3220 PoE
TC-R3220 PoE
Cases Apprecitations
To the customer’s requirements for safety, the property developer worked with system integrator to install a full Tiandy surveillance solution. This included 252pcs Tiandy starlight VF bullets and 48pcs starlight VF domes, 2pcs Tiandy 320-ch super NVR as well as Tiandy Easy7 VMS video management software.
To provide 24hr colorful image of high quality, the new cameras supported by TVP algorithm are equipped with video analytics that include loitering detection, automatically detecting people who lingers in an area for a certain time and alerting security operators. HD Dome cameras has discouraged the attempts to vandalize them, and it expands coverage to areas where surveillance was once limited because of tough viewing angles. The extra Tiandy super NVR with dual power supply can be prepared as an extra NVR, with ANR function which can store footage in the camera in case of sudden outage. With these multiple protections the system can keep running in a total secure environment.
