4MP Tiandy TC-C34GN Bullet CCTV Camera
  • 4MP Tiandy TC-C34GN Bullet CCTV Camera
  • 4MP Tiandy TC-C34GN Bullet CCTV Camera
  • 4MP Tiandy TC-C34GN Bullet CCTV Camera
4MP Tiandy TC-C34GN Bullet CCTV Camera
4MP Tiandy TC-C34GN Bullet CCTV Camera
4MP Tiandy TC-C34GN Bullet CCTV Camera

4MP Tiandy TC-C34GN Bullet CCTV Camera

  • USD30
    ≥5 Set/Sets
Payment Type:
L/C, T/T, Paypal, Money Gram, Western Union
Incoterm:
FOB, CFR, CIF, EXW
Min. Order:
5 Set/Sets
Min. Order:
5 Set/Sets
Delivery Time:
15 Days
Transportation:
Ocean, Land, Air
Port:
Shenzhen, Shanghai, Tianjin
Quantity:

Your message must be between 20 to 2000 characters

Contact Now
Basic Info
Basic Info
Place of Origin: Tianjin
Productivity: 50000 sets per week
Supply Ability: 200000 per month
Payment Type: L/C,T/T,Paypal,Money Gram,Western Union
Incoterm: FOB,CFR,CIF,EXW
Certificate: ISO9001 CE FCC SGS
HS Code: 85299049
Transportation: Ocean,Land,Air
Port: Shenzhen,Shanghai,Tianjin
Product Description
Product Description

Features


· Full Metal Housing

· Up to 1920x1080 30fps

· S+265/H.265/H.264

· Min. illumination Color: 0.0008Lux F1.6

· Smart IR, IR Range: 30m

· Operating Conditions -35°~65°, 0~95% RH

· POE, IP66

· Smart Codec/Image/Alarm





Products Details

Lite&Pro Turret Camera C32HP (2)







Lite&Pro Turret C32HN (3)

Specification

Lite Turret Camera C32GN

Camera TC-C32HP
Image Sensor 1/2.8" CMOS
Signal System PAL/NTSC
Min. Illumination Color: 0.0008Lux@ (F1.6, ACG ON), B/W: 0Lux with IR
Shutter Time 1s to 1/100,000s
Day & Night Dual IR Cut Filter with Auto Switch
Wide Dynamic Range Digital WDR
Angle Adjustment pan 0~340°, tilt 0~75°, roate 0~360°
Lens
Lens Type Fixed
Focus 2.8mm
Lens Mount M12
Aperture F1.6, Fixed
FOV Horizontal field of view: 107°
Illuminator
IR LEDs 1
IR Range Up to 30m
Wavelength 850nm
White LEDs N/A
Compression Standard
Video Compression S+265/H.265/H.264
Video Bit Rate 32 Kbps to 6 Mbps
Audio Compression N/A
Audio Bit Rate N/A
Max. Resolution 1920×1080
Main Stream PAL: 25fps (1920×1080, 1280×960, 1280×720, 704×576, 640×480)
NTSC: 30fps (1920×1080, 1280×960, 1280×720, 704×480, 640×480)
Sub Stream PAL: 25fps (704×576, 704×288, 640×360, 352×288)
NTSC: 30fps (704×480, 704×240, 640×360, 352×240)
Third Stream N/A
Image Setting Saturation, brightness, contrast, sharpness, adjustable by client software or web browser
Image Enhancement BLC/3D DNR/HLC
ROI N/A
OSD 16×16, 32×32, 48×48, adaptable size, Letters Such as Week, Date, Time, Total 1 Regions
Picture Overlay N/A
Privace Mask Yes
Smart Defog Yes
Feature
Alarm Trigger Motion Detection/IP Conflict/MAC Conflict/Mask Alarm
Video Analytics N/A
Early Warning(EW) N/A
Intelligent Coding Yes
Intelligent Image Yes
Intelligent Alarm Yes
Network
Network Storage N/A
Protocols TCP/IP, ICMP, HTTP, HTTPS, DHCP, DNS, DDNS, MULTICAST, UPnP, FTP, IPV4, NTP, RTSP, SMTP, IGMP, QoS
System Compatibility ONVIF (PROFILE S), SDK, P2P
Remote Connection ≤7
Client Easy7, EasyLive
Web Version Web5
Interface
Communication Interface 1 RJ45 10M/ 100M self adaptive Ethernet port
Audio I/O N/A
Alarm I/O N/A
Reset Button N/A
On-board storage  N/A
General
Firmware Version NVSS_V13.2.1.20190612
Web Client Language 11 languages
English, Russian, Spanish, Korean, Italian, Turkish, Simple Chinese, Traditional Chinese, Thai, French, Polish
Operating Conditions -35℃~65℃, 0~95% RH
Power Supply DC 12V±20%, PoE (802.3af)
Power Consumption MAX: 5W(12V) MAX: 6W(POE)
Protection IP66
Heater N/A
Dimensions  Φ117×96 mm (Φ4.61×3.78 inch)
Weight 0.3Kg (0.66lb)


You may  Interested


TC-C32GN,TC-C32GP,TC-C32HN

TC-C32HP,TC-C32JN,TC-C32JP,

TC-NCL214,TC-NCL214S,TC-NCL222,

TC-NCL222S,TC-NCL23MN ,TC-NCL24MN



Case Appreacifation


Adress  Istanbul, Turkey

Tiandy Intelligent Surveillance System


To customer requirements for safety, the property developer worked with system integrator to install a full Tiandy surveillance solution. This included 252pcs Tiandy starlight VF bullets and 48pcs starlight VF domes, 2pcs Tiandy 320-ch super NVR as well as Tiandy Easy7 VMS video management software.

To provide 24hr colorful image of high quality, the new cameras supported by TVP algorithm  are equipped with video analytics that include loitering detection, automatically detecting people who lingers in an area for a certain time and alerting security operators. HD Dome cameras has discouraged the attempts to vandalize them, and it expands coverage to areas where surveillance was once limited because of tough viewing angles. The extra Tiandy super NVR with dual power supply can be prepared as an extra NVR, with ANR function which can store footage in the camera in case of sudden outage. With these multiple protections the system can keep running in a total secure environment.
