5MP 30x Starlight AEW PTZ CameraTC-H356Q
- Payment Type:
- L/C, T/T, Paypal, Money Gram, Western Union
- Incoterm:
- FOB, CFR, CIF, EXW, FCA
- Min. Order:
- 5 Set/Sets
- Min. Order:
- 5 Set/Sets
- Delivery Time:
- 15 Days
- Transportation:
- Ocean, Land, Air
- Port:
- Shenzhen, Shanghai
Your message must be between 20 to 2000 characters
Contact Now| Place of Origin: | Tianjin |
|---|---|
| Productivity: | 50000 sets per week |
| Supply Ability: | 200000 per month |
| Payment Type: | L/C,T/T,Paypal,Money Gram,Western Union |
| Incoterm: | FOB,CFR,CIF,EXW,FCA |
| Certificate: | ISO9001 CE FCC SGS |
| HS Code: | 85299049 |
| Transportation: | Ocean,Land,Air |
| Port: | Shenzhen,Shanghai |
Features
· Auto-Tracking Early Warning (AEW)
· Up to 2592×1944 30fps
· Min. illumination Color: 0.002Lux F1.5
· Optical zoom: 30×, digital zoom 16×
· Built-in Speaker
· Support Human/Vehicle Classification
· Smart IR, IR Range: 150m
· S+265/H.265/H.264/M-JPEG
· IP66
Product Details
Specifications
Camera TC-H356Q
Image Sensor
1/2.8" CMOS
Signal System
PAL/NTSC
Min. Illumination
Color: 0.002lux@ (F1.5, ACG ON), BW: 0lux with IR
Shutter Time
1s to 1/100,000s
Day & Night
Dual IR Cut Filter
Wide Dynamic Range
140dB
Optical Zoom
30×
Digital Zoom
16×
Lens
Focal Length
4.7mm~141mm
Zoom Speed
<5s
Angle of View
Horizontal filed of view: 69.5° (w)～2.7° (t)
Aperture Range
F1.5~F4.0
Pan&Tilt
Pan Range
360°
Pan Speed
Pan Manual Speed: 0.1°~180°/s, Pan Preset Speed: 240°/s
Tilt Range
-16°~90° (Auto flip)
Tilt Speed
Tilt Manual Speed: 0.1°~120°/s, Tilt Preset Speed: 180°/s
3D Position
Yes
Presets
500
Preset Accuracy
±0.4°
Scan
8
Cruise
16, up to 32 presets per cruise
Pattern
8, each with 600s memory or 1000 orders
Power-off Memory
Yes
RS-485 Protocols
DOME_PELCO_D, DOME_PELCO_P, DOME_PLUS
Illuminator
IR LEDs
8
IR Range
Up to 150m
IR Irradiation Angle
Adjustable by Zoom
White LEDs
2
Compression Standard
Video Compression
S+265/H.265/H.264/M-JPEG
Video Bit Rate
32 Kbps to 16 Mbps
Audio Compression
G.711A/G.711U/ADPCM/AAC
Audio Bit Rate
8K~48Kbps
Max. Resolution
2592×1944
Main Stream
PAL: 25fps (2592×1944, 2560×1920, 2592×1520, 2560×1440, 2048×1536, 1920×1080, 1280×960, 1280×720)
NTSC: 30fps (2592×1944, 2560×1920, 2592×1520, 2560×1440, 2048×1536, 1920×1080, 1280×960, 1280×720)
Sub Stream
PAL: 25fps (704×576, 704×288, 640×360, 352×288)
NTSC: 30fps (704×480, 704×240, 640×360, 352×240)
Third Stream
PAL: 25fps (1920×1080, 1280×960, 1280×720, 640×480, 704×576, 352×288)
NTSC: 30fps (1920×1080, 1280×960, 1280×720, 640×480, 704×480, 352×240)
Image Setting
Saturation, brightness, contrast, sharpness, adjustable by client software or web browser
Image Enhancement
BLC/3D DNR/HLC
ROI
7 Dynamic Areas for Both Main and Sub Stream, support auto-tracking ROI
OSD
16×16, 24×24,32×32, 48×48, 64x64, 96x96, adaptable size, Letters Such as Week, Date, Time, Total 5 Regions
Picture Overlay
Yes
Privace Mask
Yes
Smart Defog
Yes
Feature
Alarm Trigger
Harsh Voice Alarm, Motion Detection, Mask Alarm, Port Alarm, Network Disable Alarm, IP Conflict, MAC Conflict Detection
Video Analytics
Tripwire, Double Tripwire, Perimeter, Object Abandon, Object Lost, Loitering, Running, Parking, Face Detection, People Counting, Crowed, On Duty Detection, Video Abnormal, Audio Abnormal, Heatmap, Safety Helmet Detection
Early Warning(EW)
Yes
Auto-Tracking
Yes
Network
Protocols
TCP/IP, ICMP, HTTP, HTTPS, DHCP, DNS, DDNS, MULTICAST, UPnP, FTP, IPV4, NTP, RTSP, SMTP, IGMP, QoS, PPPoE
System Compatibility
ONVIF (PROFILE S), SDK, CGI, P2P
ANR
Auto store video in SD card when NVR disconnected, and upload video to NVR when resumed connection (Only Support Tiandy ANR NVR)
Remote Connection
≤7
Client
Easy7, EasyLive
Web Version
Web5
Interface
Communication Interface
1 RJ45 10M/100M self adaptive Ethernet port
Audio
1/1
Alarm
8/2
Reset Button
Yes
On-board storage
Built-in MicroSD card slot, up to 128 GB
RS-485
Yes
BNC
Yes
Wiper
Yes
General
Firmware Version
NVSS_V14.0.6.20190328
Web Client Language
11 languages
English, Russian, Spanish, Korean, Italian, Turkish, Simple Chinese, Traditional Chinese, Thai, French, Polish
Operating Conditions
-30°~65°C, 0-95% RH
Power Supply
AC24V±15%
Power Consumption
21W (IR OFF), 44W (IR ON)
Protection
IP66
Heater
N/A
Dimensions
Φ222x372 mm (Φ8.74×14.65 inch)
Weight
5.5kg (12.13lb)
Related Products
TC-H356Q
TC-A3563
Cases Apprecitations
To the customer’s requirements for safety, the property developer worked with system integrator to install a full Tiandy surveillance solution. This included 252pcs Tiandy starlight VF bullets and 48pcs starlight VF domes, 2pcs Tiandy 320-ch super NVR as well as Tiandy Easy7 VMS video management software.
To provide 24hr colorful image of high quality, the new cameras supported by TVP algorithm are equipped with video analytics that include loitering detection, automatically detecting people who lingers in an area for a certain time and alerting security operators. HD Dome cameras has discouraged the attempts to vandalize them, and it expands coverage to areas where surveillance was once limited because of tough viewing angles. The extra Tiandy super NVR with dual power supply can be prepared as an extra NVR, with ANR function which can store footage in the camera in case of sudden outage. With these multiple protections the system can keep running in a total secure environment.
