Waste Isolated Oil Reclamation Machine
- Payment Type:
- L/C, T/T, Western Union
- Incoterm:
- FOB, CFR, CIF, EXW
- Min. Order:
- 1 Set/Sets
- Min. Order:
- 1 Set/Sets
- Delivery Time:
- 7 Days
- Transportation:
- Ocean, Air
- Port:
- Shanghai, Chongqing, Shenzhen
Your message must be between 20 to 2000 characters
Contact Now| Place of Origin: | Chongqing,China |
|---|---|
| Productivity: | 700 sets per month |
| Supply Ability: | 700 sets per month |
| Payment Type: | L/C,T/T,Western Union |
| Incoterm: | FOB,CFR,CIF,EXW |
| Certificate: | ce,iso |
| Transportation: | Ocean,Air |
| Port: | Shanghai,Chongqing,Shenzhen |
Waste Isolated Oil Reclamation Machine Waste Transformer Oil Purifier
1.Easy installation and operation;
2.Energy saving and low operating cost;
3.Little maintenance and overhaul reduction
It is applied to treat various unqualified insulation oils, including aging transformer oil, swich oil ect.
1. Bi-infrared liquid Duplex 3D evaporation technology, dewatering and degassing very effectively;
2. Distinctive removing the impurities technology of filtering through double FH trapezoidal network and absorbing by high polymer without the mechanical power;
3. Bi-infrared liquid level automatic controller system;
4. Trinity interlocked preventive device;
5. It can work independently also can work with the oil regeneration system;
6. It can work as the vacuum oiling machine or vacuum drying machine to the power equipment, like transformer;
7. Automatic testing the oil dielectric strength and printing out the result.
It is a new type of high effective vacuum oil purifier with the duplex 3D stereo-evaporation technology and G technology. Adopting the technology, which removes the impurities through double FH trapezoidal network and absorbs by high polymer without mechanical power. It’s five to eight times more effective than the common vacuum oil purifiers. The consumption of power is low and it doesn’t require other wearing materials
Technical Parameter
| Item | Unit | ZY-10 | ZY-20 | ZY-30 | ZY-50 | ZY-100 | ZY-150 | ZY-200 | ZY-300 |
| Flow Rate | L/min | 10 | 20 | 30 | 50 | 100 | 150 | 200 | 300 |
| Vacuum Degree | MPa | -0.06 ～ -0.095 | |||||||
| Working Pressure | MPa | ≤0.4 | ≤0.4 |
≤0.4
|
≤0.5 | ≤0.5 | ≤0.5 | ≤0.5 | ≤0.5 |
| Temperature Range | ℃ | 20-80 | |||||||
| Continuous Working | Hour | 150 | |||||||
|
Power Supply
|
380V/ 50HZ/ 3Phase(As per client’s request) | ||||||||
| Working Noise | dB(A) | ≤75 | ≤75 | ≤75 | ≤75 | ≤80 | ≤80 | ≤80 | ≤80 |
| Heating Power | kW | 11 | 13 | 15 | 30 | 48 | 58 | 70 | 85 |
| Total Power | kW | 12.5 | 14.5 | 16.5 | 33.5 | 53 | 65 | 76 | 94 |
| Inlet (outlet)Caliber | mm | 25 | 25 | 25 | 32 | 42 | 50 | 50 | 60 |
| Weight | kg | 230 | 250 | 270 | 300 | 550 | 700 | 950 | 1200 |
| Dimension | Length | mm | 1050 | 1100 | 1150 | 1200 | 1600 | 1600 | 1800 |
| Width | mm | 750 | 850 | 900 | 950 | 1000 | 1100 | 1200 | |
| Height | mm | 1300 | 1400 | 1450 | 1500 | 1800 | 1800 | 1900 | |
| After Purification | |||||||||
| Breakdown Voltage | kV | ＞60 | |||||||
| Water Content | PPM | ＜4 | |||||||
| Gas Content | % | ＜0.1 | |||||||
| Particles Size | μm |
＜3 |
|||||||
